ACR SM3 Marker Light: Enhancing Marine Safety and Visibility

ACR SM3 Marker Light

Model: 3947

• Bright light in all directions (360° visibility)
• UV resistant polycarbonate case
• Light weight and compact in size
• Easy bracket installation
• Bracket is included and maintains same hole pattern as SM-2 for easy retrofit
• Automatically rights itself and activates when in the water
• High intensity LED strobe
• Floats upright in all conditions
• Minimum 40 hours continuous operating life at 30oC (86oF) or over 24 hours at -1oC (30oF)
• User Replaceable AA Energizer L91 Lithium Batteries (Not Included)

The SM-3 is a high intensity LED strobe which provides 360° visibility for approximately 2 miles. This compact yet durable marker light facilitates rescue by automatically activating and beginning to strobe when in the water, working for over 40 hours at 30oC (86oF) or over 24 hours at -1oC (30oF). Perfect for commercial marine, petro-marine, cruisers, and any other application needing a reliable Crew Overboard Marker (COB) light, the SM-3 floats upright in all conditions, ensuring it will keep shining when you need it the most.

With a minimum light intensity of 3 candelas throughout its entire operating life, this high intensity LED strobe clearly marks a crew-overboard site with each brilliant flash. It automatically rights itself and activates when in the water, ensuring that activation is never an issue that a crew member in distress needs to worry about. The SM-3 operates on 2 AA Lithium batteries and the batteries are user replaceable, allowing the potential for a longer product life than the many disposable lifebuoy lights on the market.

The supplied mounting bracket holds the SM-3 secure in the roughest of conditions but it is still readily accessible when needed in an emergency. Additionally, while the SM-3 and its bracket are significantly smaller than the SM-2 counterparts, the SM-3 bracket conveniently maintains the same mounting hole pattern as the SM-2, allowing for easy retrofit with no additional adapter plate required.

The SM-3 is USCG/MED/SOLAS approved for use around the world and this durable LED marker light therefore provides an excellent option for vessels needing to meet USCG and SOLAS carriage requirements for lifebuoy self-igniting lights. As per USCG and SOLAS requirements for passenger and cargo vessels, at least one-half of the total number of lifebuoys on the vessel must be fitted with a self-igniting light. Minimum carriage requirements are based on the length of the vessel and can range from a minimum of four to a minimum of fifteen lifebuoys with self-igniting lights per vessel.

Rugged design leads to greater flexibility of use. While the SOLAS standard only calls for a 30-meter drop test, the SM-3 has been drop tested to 76 meters. This makes the SM-3 a versatile option for use on a variety of platforms or vessels of different sizes.

With its easily replaceable Lithium AA battery power source, the SM-3 will give years of service and be ready when called upon.

Specifications

Name
SM-3 Lifebuoy Self-Igniting Marker Light

Product Description
Strobing Crew-Overboard Marker Light

Model Number
SM-3

Application
Commercial maritime applications including petro-marine, workboats, cruise liners, tugs and workboats, supply vessels, cargo vessels, passenger vessels, fishing charters etc.

Size

Length
9.9" (253 mm)

Diameter
2.2" (56 mm)

Weights

Light Only
0.66 lbs (300 g)

Light with Batteries
0.71 lbs (330 g)

Light with Batteries & Bracket
0.90 lbs (406 g)

Batteries
2 AA Lithium Batteries (L91) / User Replaceable (Not Included)

Material
UV Resistant Polycarbonate

Color
International Safety Orange

Activation
Automatic gravity switch

Operation
Throw SM-3 overboard or turn upright and strobe light will automatically begin to flash

Light Intensity
Minimum of 3 candelas per flash in all directions of upper hemisphere

Visibility
360o visibility

Flash Rate
50—70 times per minute

Buoyant
Yes

Lamp
Ultra-Bright LED

Operational Life
40 hours over 3 cd at 30oC (86oF)

Drop Test
Drop tested to 76 meters (USCG/SOLAS/MED only call for 30 meters)

Warranty
1 year

Mounting Bracket
UV resistant polycarbonate bracket included / Same mounting hole pattern as previous SM-2 Model for easy retrofit

Durability and Design of ACR SM3 Marker Light

The ACR SM3 Marker Light is engineered for rugged marine environments where reliability is critical. Made with high-quality materials, it offers exceptional resistance to saltwater corrosion and harsh weather conditions. Its compact, waterproof design ensures long-lasting performance, making it an ideal choice for boaters who need a dependable navigation aid. The ACR SM3 is lightweight yet sturdy, allowing easy installation on various vessels while maintaining superior durability.

Brightness and Visibility Features

The ACR SM3 Marker Light features a powerful LED system that provides bright, steady illumination, enhancing visibility in low-light or foggy conditions. The light's advanced optics create a wide beam spread to ensure maximum effectiveness for night navigation. Its energy-efficient design extends battery life, making it environmentally friendly and cost-effective. Bright and clear, the ACR SM3 helps boats stay visible to other vessels, reducing the risk of collisions on open waters.

Ease of Use and Maintenance

Designed with user convenience in mind, the ACR SM3 Marker Light is easy to install and operate. It includes intuitive controls and a secure mounting system compatible with most boat types. Maintenance is minimal thanks to its sealed unit design, which prevents water ingress and electrical issues. The light’s long-lasting battery ensures extended usage time, minimizing the need for frequent replacements. Overall, the ACR SM3 is a reliable and practical navigation tool trusted by marine professionals worldwide.
