Airmar B75C-12-L 12d Tilt Low CHIRP Furuno 12-Pin Cable

Airmar B75C-12-L: High-Performance 12d Tilt Low CHIRP Transducer with Furuno 12-Pin Cable

Airmar B75C-12-L 12d Tilt Low CHIRP Furuno 12-Pin Cable

Airmar B75C-12-L 12d Tilt Low CHIRP with Furuno 12-Pin Mix-N-Match Cable

Model: B75C-12-L-12F

• Depth & fast-response water-temperature sensor
• Low-CHIRPS from 40 kHz to 75 kHz, 32 deg to 21 deg beamwidth
• 300 W of power with a maximum depth of 353 m (1200 feet)
• Great deep-water performance
• Low-profile, thru-hull housing provides good display resolution at speed when installed properly
• Recommended for stepped, planing, or displacement hull
• Bronze housing for use in a fiberglass or wood hull

Airmar's low-profile, Chirp-ready transducer models are the perfect addition to smaller boats such as center consoles. The low-frequency band, operating between 40 and 75 kHz, is a deep-water performer, providing excellent coverage and tracking. The B75L transducer delivers up to 35 kHz of total bandwidth in just one installation.

When the transducer is installed almost flush to the hull, the tilt of the element corrects for the hull deadrise, orienting the beam directly down. This ensures maximum echo returns to the transducer for more accurate depth readings.

Provides greater depth range, wider beamwidth, and ultimately more coverage under the boat

Chirp signal processing technology used with AIRMAR broadband, Chirp-ready transducers provides more detail at greater depths and is less susceptible to noise

Great for operating at high boat speeds

Specifications

Cable-Length9 m (30 feet)

Deadrise Range
8 to 16 deg

Frequency Band
Low

Low Frequency
40-75 kHz

Low Frequency Beamwidth
32 deg-21 deg

Max Depth
366 m (1200 feet)

Power Rating
300 W

Retractable housing
No

Single or Dual Frequency
CHIRP-Ready Single-Band

Transducer Functions
Depth, Temperature

What's in the Box:

• B75C-12-L-MM
• MMC-12F Cable

Advanced Low CHIRP Technology for Clear Sonar Imaging

The Airmar B75C-12-L integrates advanced low CHIRP technology, providing excellent target separation and clearer sonar imaging. Designed to outperform traditional single-frequency transducers, this 12d tilt transducer enhances underwater visibility by reducing noise and improving fish detection. Its wide frequency range optimizes performance in diverse water conditions, making it ideal for both recreational and commercial marine users relying on precise sonar data.

Durable 12d Tilt Design for Versatile Installation

This model features a robust 12-degree tilt design allowing flexible mounting options to ensure optimal transducer alignment. The tilt angle helps reduce hull interference and improves signal clarity, enhancing sonar effectiveness especially on boats with various hull shapes. The sturdy build ensures lasting durability in harsh marine environments, providing peace of mind for long-term use on multiple vessel types.

Compatible Furuno 12-Pin Cable for Seamless Connection

The Airmar B75C-12-L comes with a Furuno 12-pin cable designed for straightforward integration with Furuno sonar systems. This cable supports stable data transmission and power supply, ensuring reliable and consistent performance. The connector's secure fit minimizes connection issues, making installation quick and hassle-free for users aiming for professional-grade sonar setup.
