Airmar B75C-12-L 12d Tilt Low CHIRP Garmin 8-Pin Cable

Airmar B75C-12-L: Advanced Low CHIRP Transducer with Garmin 8-Pin Cable

Airmar B75C-12-L 12d Tilt Low CHIRP Garmin 8-Pin Cable

Airmar B75C-12-L 12d Tilt Low CHIRP with Garmin 8-Pin Mix-N-Match Cable

Model: B75C-12-L-8G

• Depth & fast-response water-temperature sensor
• Low-CHIRPS from 40 kHz to 75 kHz, 32 deg to 21 deg beamwidth
• 300 W of power with a maximum depth of 353 m (1200 feet)
• Great deep-water performance
• Low-profile, thru-hull housing provides good display resolution at speed when installed properly
• Recommended for stepped, planing, or displacement hull
• Bronze housing for use in a fiberglass or wood hull

Airmar's low-profile, Chirp-ready transducer models are the perfect addition to smaller boats such as center consoles. The low-frequency band, operating between 40 and 75 kHz, is a deep-water performer, providing excellent coverage and tracking. The B75L transducer delivers up to 35 kHz of total bandwidth in just one installation.

When the transducer is installed almost flush to the hull, the tilt of the element corrects for the hull deadrise, orienting the beam directly down. This ensures maximum echo returns to the transducer for more accurate depth readings.

Provides greater depth range, wider beamwidth, and ultimately more coverage under the boat

Chirp signal processing technology used with AIRMAR broadband, Chirp-ready transducers provides more detail at greater depths and is less susceptible to noise

Great for operating at high boat speeds

Specifications

Cable-Length9 m (30 feet)

Deadrise Range
8 to 16 deg

Frequency Band
Low

Low Frequency
40-75 kHz

Low Frequency Beamwidth
32 deg-21 deg

Max Depth
366 m (1200 feet)

Power Rating
300 W

Retractable housing
No

Single or Dual Frequency
CHIRP-Ready Single-Band

Transducer Functions
Depth, Temperature

What's in the Box:

• B75C-12-L-MM
• MMC-8G Cable

High-Performance Low CHIRP Technology

The Airmar B75C-12-L stands out as a high-performance low CHIRP transducer designed to enhance your marine electronics system. Specially engineered to emit a 12-degree tilt beam angle, it ensures a more focused sonar cone that delivers sharper and more detailed underwater imaging. This precision makes it ideal for anglers and boaters who demand accurate fish detection and bottom structure identification. Compatible with Garmin fishfinders featuring an 8-pin cable connection, the B75C-12-L offers seamless integration, maximizing your vessel's sonar capabilities without compromising reliability.

Durable Build for Marine Environments

Built to withstand harsh marine environments, the Airmar B75C-12-L features a robust composite housing designed for long-lasting durability. Its rugged exterior resists corrosion, impact, and pressure, which is essential for extended use in saltwater and freshwater conditions. The included Garmin 8-pin cable provides secure and waterproof connectivity, preventing signal loss and ensuring consistent data transmission. These features collectively contribute to a reliable sonar experience, giving boaters confidence in their equipment regardless of challenging conditions.

Easy Installation and Versatile Applications

The Airmar B75C-12-L transducer is designed for straightforward installation on a variety of boats. Its 12-degree tilt angle aids in positioning for optimal sonar coverage, particularly on vessels with hull deadrise. The Garmin 8-pin cable simplifies the connection process, eliminating compatibility concerns. This transducer works well for fishing, navigation, and underwater exploration, making it a versatile tool for marine enthusiasts. Whether installing a new system or upgrading an existing unit, the Airmar B75C-12-L ensures enhanced performance and ease of use.
