Airmar B75C-12-L 12d Tilt Low CHIRP Humminbird 14-Pin Cable

Airmar B75C-12-L: Advanced Low CHIRP Transducer for Humminbird Systems

Airmar B75C-12-L 12d Tilt Low CHIRP Humminbird 14-Pin Cable

Airmar B75C-12-L 12d Tilt Low CHIRP with Humminbird 14-Pin Mix-N-Match Cable

Model: B75C-12-L-14HB

• Depth & fast-response water-temperature sensor
• Low-CHIRPS from 40 kHz to 75 kHz, 32 deg to 21 deg beamwidth
• 300 W of power with a maximum depth of 353 m (1200 feet)
• Great deep-water performance
• Low-profile, thru-hull housing provides good display resolution at speed when installed properly
• Recommended for stepped, planing, or displacement hull
• Bronze housing for use in a fiberglass or wood hull

Airmar's low-profile, Chirp-ready transducer models are the perfect addition to smaller boats such as center consoles. The low-frequency band, operating between 40 and 75 kHz, is a deep-water performer, providing excellent coverage and tracking. The B75L transducer delivers up to 35 kHz of total bandwidth in just one installation.

When the transducer is installed almost flush to the hull, the tilt of the element corrects for the hull deadrise, orienting the beam directly down. This ensures maximum echo returns to the transducer for more accurate depth readings.

Provides greater depth range, wider beamwidth, and ultimately more coverage under the boat

Chirp signal processing technology used with AIRMAR broadband, Chirp-ready transducers provides more detail at greater depths and is less susceptible to noise

Great for operating at high boat speeds

Specifications

Cable-Length9 m (30 feet)

Deadrise Range
8 to 16 deg

Frequency Band
Low

Low Frequency
40-75 kHz

Low Frequency Beamwidth
32 deg-21 deg

Max Depth
366 m (1200 feet)

Power Rating
300 W

Retractable housing
No

Single or Dual Frequency
CHIRP-Ready Single-Band

Transducer Functions
Depth, Temperature

What's in the Box:

• B75C-12-L-MM
• MMC-14HB Cable

High Performance with 12° Tilt Angle

The Airmar B75C-12-L transducer features a precise 12-degree tilt angle designed to optimize sonar signal direction and improve underwater coverage. This realistic tilt helps enhance fish detection and contour imaging, providing a clearer and more detailed sonar picture. Its angled design makes it an excellent choice for anglers and boaters looking for better target separation in both shallow and deep waters. The 12° tilt ensures you get precise readings around your vessel, maximizing your fishing or navigation experience with your Humminbird 14-pin cable compatible systems.

Low CHIRP Technology for Enhanced Sonar Clarity

The Airmar B75C-12-L incorporates advanced Low CHIRP technology, which transmits a continuous range of frequencies to deliver superior target resolution and reduced noise. This technology significantly improves the clarity of underwater images by producing less interference and better target separation. The result is a sharper, more reliable sonar display that lets you distinguish fish from debris or vegetation easily. Compatible with Humminbird fish finders, this transducer enhances your ability to make informed decisions on the water.

Durability and Easy Integration with 14-Pin Cable

Built with high-quality materials, the Airmar B75C-12-L is designed to withstand harsh marine environments, including saltwater exposure. Its rugged construction ensures long-lasting reliability and consistent performance throughout the fishing season. The transducer comes with a 14-pin cable, making it fully compatible with a wide range of Humminbird sonar and fish finder units for seamless integration. Installation is straightforward, and the cable design minimizes signal loss, helping you maintain accurate sonar data and enjoy a stable connection on your boat.
