Airmar B75C-12-L 12d Tilt Low CHIRP Humminbird 9-pin Cable

Airmar B75C-12-L: Advanced 12d Tilt Low CHIRP Transducer Cable

Airmar B75C-12-L 12d Tilt Low CHIRP Humminbird 9-pin Cable

Airmar B75C-12-L 12d Tilt Low CHIRP with Humminbird 9-Pin Mix-N-Match Cable

Model: B75C-12-L-HB

• Depth & fast-response water-temperature sensor
• Low-CHIRPS from 40 kHz to 75 kHz, 32 deg to 21 deg beamwidth
• 300 W of power with a maximum depth of 353 m (1200 feet)
• Great deep-water performance
• Low-profile, thru-hull housing provides good display resolution at speed when installed properly
• Recommended for stepped, planing, or displacement hull
• Bronze housing for use in a fiberglass or wood hull

Airmar's low-profile, Chirp-ready transducer models are the perfect addition to smaller boats such as center consoles. The low-frequency band, operating between 40 and 75 kHz, is a deep-water performer, providing excellent coverage and tracking. The B75L transducer delivers up to 35 kHz of total bandwidth in just one installation.

When the transducer is installed almost flush to the hull, the tilt of the element corrects for the hull deadrise, orienting the beam directly down. This ensures maximum echo returns to the transducer for more accurate depth readings.

Provides greater depth range, wider beamwidth, and ultimately more coverage under the boat

Chirp signal processing technology used with AIRMAR broadband, Chirp-ready transducers provides more detail at greater depths and is less susceptible to noise

Great for operating at high boat speeds

Specifications

Cable-Length9 m (30 feet)

Deadrise Range
8 to 16 deg

Frequency Band
Low

Low Frequency
40-75 kHz

Low Frequency Beamwidth
32 deg-21 deg

Max Depth
366 m (1200 feet)

Power Rating
300 W

Retractable housing
No

Single or Dual Frequency
CHIRP-Ready Single-Band

Transducer Functions
Depth, Temperature

What's in the Box:

• B75C-12-L-MM
• MMC-HB Cable

Superior Compatibility with Humminbird Systems

The Airmar B75C-12-L is engineered specifically for seamless integration with Humminbird sonar units, featuring a 9-pin connection that ensures reliable signal transmission. This direct compatibility eliminates the need for adapters, providing users with easy installation and consistent performance. Its design supports various Humminbird models, making it a preferred choice for anglers and marine professionals who demand accurate underwater data.

Enhanced Imaging with 12° Tilt and Low CHIRP Technology

Equipped with a 12-degree tilt, the Airmar B75C-12-L transducer improves sonar beam angles to optimize target separation and reduce signal noise. The Low CHIRP (Compressed High-Intensity Radiated Pulse) technology further enhances detail resolution, allowing clearer imaging of fish, structure, and bottom contours. This combination delivers exceptional underwater clarity, making it easier to identify targets and navigate diverse aquatic environments.

Durability and Precision in Marine Conditions

Designed for durability, the Airmar B75C-12-L features robust housing and cable construction that withstands harsh marine environments. Its sealed design prevents water intrusion, ensuring consistent performance over time. The cable's 9-pin connector is crafted for secure, corrosion-resistant connections, providing long-lasting reliability. This durability safeguards your investment and ensures precise sonar feedback during extended use on lakes, rivers, or coastal waters.
