SKU:AIRR599CLH
Airmar R599C-LH In Hull 3kW Low/High CHIRP No Connector
Airmar R599 Low-High Chirp, 3kW, No Connector, Depth
Model: R599C-LH
The R599LH is the go-to transducer for today's top captains who want the maximum depth capability combined with the excellent target resolution of the high-frequency band. This powerhouse shows extreme target detail, bottom discrimination, and bait and game-fish separation at all depths. The R599LH is packed with a twenty-four element, low-frequency array that operates at anywhere between 28 and 60 kHz. The single, high-frequency ceramic operates at any frequency between 130 and 210 kHz and has a narrow, 8 deg to 4 deg, beam, delivering amazing target resolution and bottom detail.
The transducer is installed in the included tank which is cut to the boat's deadrise angle and affixed inside the hull. When the transducer is placed inside the tank, it is properly oriented for optimal performance. The R599LH is a popular choice for customers not wanting to drill a hole in their hull and for trailered or multi-hull boats.
Specifications
Cable-Length15 m (49 feet)
Connector
Bare Wire
Cross Reference
A80212
Deadrise Range
0 deg to 22 deg
Display Connector
0
Frequency Band
Low-High
Housing Material
Urethane
Hull Material
Solid fiberglass only
Low Frequency
28-60 kHz
Low Frequency Beamwidth
23 deg-9 deg
Max Deadrise
Up to 22 deg (short side), up to 12 deg (long side)
Max Deadrise Angle
22 deg
Max Depth
Low frequency- 3048 m (10000 feet), High frequency- 457 m (1500 feet)
Max Vessel LOA
12 m (40 feet) and above
High Frequency
130-210 kHz
High Frequency Beamwidth
8 deg-4 deg
Mounting Style
In-Hull
Power Rating
2-3 kW
Single or Dual Frequency
CHIRP-Ready Dual-Band
Tilted Element
No
What's in the Box:
The Airmar R599C-LH transducer is engineered for in-hull mounting, offering seamless integration with your boat's hull. This design optimizes signal clarity by transmitting sonar pulses through the hull without direct water exposure. As part of Airmar’s trusted product line, it reduces drag and protects the unit from physical damage and marine growth. If you're looking for reliable, low-maintenance sonar capabilities, this in-hull transducer delivers consistent performance perfect for fishing and navigation, all while maintaining your vessel’s hydrodynamic efficiency.
Equipped with a 3kW power rating, the Airmar R599C-LH supports both low and high CHIRP frequencies, enhancing signal resolution and depth capability. This dual-frequency performance enables anglers and boaters to detect fish and underwater structures with impressive clarity. The CHIRP technology sweeps across multiple frequencies to provide a clearer, more detailed sonar image than traditional single-frequency transducers. Whether you need to cover wide depths or identify precise targets, this transducer is designed to deliver reliable results under various water conditions.
The R599C-LH model comes without a connector, allowing for custom cabling solutions tailored to your system’s requirements. This feature offers flexibility for professional installations where compatibility with specific sonar units or wiring setups is needed. Airmar’s no-connector approach also means fewer potential failure points, as cables can be securely sealed and protected during installation. This transducer is ideal for boat owners who prefer professional customization, ensuring a neat, durable, and watertight setup.
