Analytic Systems Waterproof IP66 DC Converter VCH10W-24 10A 24V Output, 30-80V Input, Ruggedized Design

Waterproof IP66 DC Converter 10A, 24V Out, 30-80V In, Ruggedized

The VCH10 Step Down series of Voltage Converters supply up to 10 amps of output current at 12, 24, 36 or 48 volts from any higher voltage between 20 and 80 volts DC in an IP66 rated watertight and EMC shielded enclosure for use in rugged environments.

The standard VCH10W model offers a Deutsch connector on a pigtailinput/output cable, and the military grade VCH10MW features separatebayonet style MIL connectors for input and output.

The all surface mount high frequency design offers higher reliability,higher efficiency (more than 92%), more power (up to 544 watts at 48VDC Out) and minimum size.

The VCH10MW is rated for operation from -40 to +55 degrees C andhas been tested and confirmed to meet MIL-STD-461F for radiated andconducted emissions. It is designed to meet MIL-STD-810G for shock andvibration.

The unit has reverse input protection, output current limiting and output over-voltage protection.

Features:

• Watertight O-ring sealed and EMC gasketed enclosure
• MIL connectors
• Output ON and Overload LED indicators
• Compact size and easy mounting
• Up to 80V input
• Heavy duty ruggedization with wide temperature range
• Paralleling diodes
• Custom output voltages available
• Two year warranty (parts and labor)

The Analytic Systems Waterproof IP66 DC Converter VCH10W-24 provides reliable power conversion in demanding environments with its rugged and waterproof IP66 rated enclosure. Capable of delivering up to 10 amps of continuous current at a 24V output, this converter accepts input voltages ranging from 30 to 80V DC, making it suitable for a variety of high-voltage power sources. Its high-frequency design ensures high efficiency exceeding 92%, minimizing energy loss and heat generation while offering a compact form factor ideal for tight installation spaces. The unit features a Deutsch connector on a pigtail cable for straightforward wiring and an all-surface mount construction that enhances durability and ease of mounting in industrial or outdoor settings.

Features:

• Watertight O-ring sealed and EMC gasketed enclosure for protection against water and electromagnetic interference

• Deutsch connector on a pigtail cable for simplified connection

• Output ON and Overload LED indicators for status monitoring

• Compact size with easy mounting options for versatile installation

• Accepts input voltages up to 80V DC for flexible power sourcing

• Designed for rugged environments with a wide operating temperature range from -40 to +55 degrees Celsius

• Heavy-duty construction meeting MIL-STD-810G shock and vibration standards

• Includes reverse input protection, output current limiting, and over-voltage protection for enhanced safety

• Paralleling diodes available for increased power capacity

• Custom output voltages can be specified to meet specific application needs

• Covered by a two-year warranty for parts and labor
