Ancor 16/2 Safety Duplex Marine Cable - 500 Feet

16/2 Safety Duplex Cable - 500'

Features red and yellow Marine Grade primary conductors in a white common jacket.

ANCOR recommends yellow wire as DC negative because black is the standard color for AC hot. There have been many cases of people working on their DC systems who have inadvertently cut the live AC wire. Because of the wide spread use of inverters, power generators and shore power connections, even todays smallest boats pose a risk of inadvertently cutting into AC wires when working on DC systems.

ANCOR Duplex Cables are made to surpass the highest UL Boat Cable standards with ultra flexible (Type 3/Class K) stranding to resist fatigue due to
vibration and flexing

Features:

• Outer jacket is made for easy removal and provides the best abrasion resistance available

• ANCOR's proprietary premium vinyl insulation stays flexible even in extreme cold and resists salt water, batteryacid, oil, gasoline and ultra-violet radiation. Exclusive insulation is rated at 600V, 105 C dry and 75 Cwet, and is resistant to heat and abrasion

• Inner conductors are correctly color-coded to ABYC standards

WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

The Ancor 16/2 Safety Duplex Marine Cable is designed for reliable electrical connections on boats, offering a 500-foot length suitable for various marine applications. This cable features red and yellow primary conductors within a durable white jacket, with the yellow wire recommended by ANCOR for DC negative connections to prevent accidental cutting into live AC lines. With the increasing use of inverters, power generators, and shore power, safety and accurate wiring are more critical than ever. This duplex cable is manufactured to exceed UL Boat Cable standards, incorporating ultra-flexible Type 3/Class K stranding to withstand vibration and repeated flexing, ensuring longevity and consistent performance in demanding marine environments. The outer jacket is engineered for easy removal and excellent abrasion resistance, protecting internal conductors from damage caused by friction, saltwater, and other harsh elements. The proprietary vinyl insulation remains flexible in extreme cold, resisting salt water, battery acid, oil, gasoline, and ultraviolet radiation. Rated at 600 volts and capable of operating at 105°C dry or 75°C wet, this insulation provides a high level of safety and durability. Inside, the conductors are color-coded according to ABYC standards, simplifying installation and maintenance tasks. Proper wiring is essential for marine safety, and this cable's construction ensures it performs reliably under challenging conditions. Please note that this product contains chemicals such as di(2-ethylhexyl)phthalate (DEHP), which are recognized by the State of California to cause health risks, including cancer and reproductive harm. For more information, visit the P65Warnings.ca.gov website. The Ancor 16/2 Safety Duplex Marine Cable combines safety, flexibility, and durability, making it an ideal choice for marine electrical systems that demand high standards of quality and reliability.

Features:

• Outer jacket designed for easy removal and abrasion resistance

• Proprietary vinyl insulation remains flexible in extreme cold and resists salt water, battery acid, oil, gasoline, and UV radiation

• Rated at 600V with operating temperatures up to 105°C dry and 75°C wet

• Color-coded conductors according to ABYC standards

• Ultra-flexible Type 3/Class K stranding to resist fatigue from vibration and flexing
