Black Oak LED Nitron XD Marine Night Vision Camera with Standard Mount and HD Resolution

Nitron XD Night Vision Camera - White Housing - Standard Mount

The Nitron XD Marine Night Vision Camera displays the highest resolution possible, giving users crystal clear imagery in pitch black darkness. Without relying on thermal temperatures, users will have the perfect HD image in any nighttime condition. Boasting an IP69K rating, the Nitron XD can withstand the harshest environments.

With the ability to connect right into a Garmin, Simrad, Raymarine, or many other monitors, installing Black Oak's marine video camera is practically plug-n-play. With the included cable, plug right into a video input port.

*This version is the standard mount version

Hyper-Low Lux Sensor

Nitron XD was specifically designed to function in complete darkness, providing crystal-clear HD video in any nighttime environment, no matter the ambient temp.

2X The Resolution

See more than just silhouettes; Nitron XD shows details in full HD.

Marine Rated

This Black Oak' camera can withstand heavy spray and handle immersion up to 3 feet for over 60 hours.

Easy Installation

Black Oak includes everything needed to easily install, along with a plug-and-play harness to fully integrate with a MFD.

Plug-N-Play with MFD

Easily connect to a Garmin, Simrad, or other popular MFD with the supplied brand specific video input cable. See why Black Oak is the #1 night vision camera for boating.

Do it at Night

Turn night into day and achieve peace of mind with the ability to see channel markers, boats, buoys, and other hazardous objects.

Built to Last

With Black Oak's military-grade housing, there is no need to worry about this camera withstanding the harsh marine environments. Black Oak's camera is designed to handle any salt, corrosion, humidity, or moisture users throw at it.

Quick Connect

Take advantage of Black Oak's easy-access quick connect harness. With the ability to easily remove or attach, users never have to worry about leaving this camera.

Features:

• .0000025 Lux starlight night vision
• Two field of view options: 20 or 30 degrees
• Streams 752 x 582 HD video
• 60 frames per second
• Marine grade waterproof housing
• Connect directly to a MFD
• Flexible installation (top or bottom mount)
• 12Vdc power (fused)
• NTSC/PAL analog video connection (BNC)
• Manual vertical tilt adjustment
• Marine grade IP69K waterproof housing

Technical Specifications:

• Hyper Low Lux: .0000025
• HD Resolution: 752(H) x 582(V)
• Power Consumption: 1.38 Watts
• Frame Refresh Rate: 60 frames per second
• Noise Reduction: 3DNR
• Length (front to end): 8-3/16
• Height (top to bottom): 6

In the Box:

• Nitron XD Marine Camera System
• 25' quick connect wiring harness
• 5A inline fuse
• Anodized aluminum mounts

*Sold as an Individual

The Black Oak LED Nitron XD Marine Night Vision Camera offers exceptional clarity with its high-resolution imaging capabilities, providing users with crystal-clear visuals even in complete darkness. Designed for demanding marine environments, this camera features a hyper-low lux sensor that delivers HD video in pitch-black conditions without relying on thermal imaging technology. Its IP69K waterproof rating ensures durability against heavy spray, immersion up to 3 feet for over 60 hours, and harsh weather conditions, making it an ideal choice for serious boaters and marine professionals.
Installation is straightforward, thanks to the included plug-and-play harness compatible with popular multifunction displays such as Garmin, Simrad, and Raymarine. The camera’s flexible mounting options, including top or bottom mount, allow for versatile positioning to suit various vessel layouts. With a 25-foot quick connect wiring harness and an anodized aluminum mount, setup is quick, secure, and designed to withstand salt, humidity, and corrosion. The camera streams a sharp 752 x 582 HD video at 60 frames per second, providing smooth, detailed imagery necessary for navigation and safety during nighttime operations.
Equipped with manual vertical tilt adjustment and two field-of-view options—20 or 30 degrees—the Nitron XD allows precise framing and wide-angle coverage as needed. Its robust housing and military-grade construction ensure reliable performance in the most challenging marine environments. The camera's low power consumption of just 1.38 watts and compatibility with NTSC/PAL video signals make it an efficient and versatile addition to any marine setup. Included in the package are the camera system, a 25-foot wiring harness, a 5A inline fuse, and anodized aluminum mounts, providing everything required to install and operate the system efficiently. Whether navigating at night or monitoring your vessel from a distance, the Black Oak Nitron XD delivers dependable, high-quality night vision imaging for safer, more confident boating experiences.

Features:

• Starlight night vision sensor with .0000025 Lux sensitivity for exceptional low-light performance

• Two field of view options: 20 and 30 degrees for flexible viewing angles

• Streams 752 x 582 HD video at 60 frames per second for smooth, detailed imagery

• Marine-grade waterproof housing with IP69K rating for durability in harsh conditions

• Easy plug-and-play connection to Garmin, Simrad, Raymarine, and other MFDs

• Flexible installation options including top or bottom mount

• Manual vertical tilt adjustment for precise framing

• Low power consumption at 1.38 Watts

• Compatible with NTSC/PAL analog video inputs (BNC connector)

• Designed to withstand salt, corrosion, humidity, and moisture for long-lasting use
