Water-resistant bussing for harsh environments. Built with wing screws for toolless access.
Features:
Accepts a wide range of wire sizes
Includes 3 wire plugs to maintain a water-resistant rating if less than 4 wires are used
Nests with other water-resistant 100A common busbars and ST-Blade water resistant fuse block for space-saving wiring
Ideal for positive distribution and for the collection of negative or AC ground circuits
Meets ABYC/USCG insulation requirements
Tin-plated copper busses and fuse clips
Includes four (4) write-on circuit labels
Small format standard and custom labels are available
Wing-screws designed for tool-free installation of cover to meet ABYC compliance
Technical Specifications:
Cover - yes
Maximum Voltage - 300V AC - 48V DC
Terminal Stud - 1 x #10-32
Continuous Rating - 100A AC or DC
Bus Material - Tin-plated Copper
Mounting Holes - Accepts 1/4" (6mm) screws
Terminal Screws - 4 x # 8-32
Wire Size - Input - (1) 8 AWG to 4 AWG
Wire Size - Load - (4) 16 AWG to 10 AWG
In the Box:
2356100 Busbar
Instruction Manual
*Sold as an Individual
The Blue Sea Systems 2356100 is a durable, water-resistant busbar designed for demanding environments such as marine applications. Constructed with tin-plated copper, this busbar provides reliable electrical distribution with a maximum continuous rating of 100 amps at up to 300 volts AC or 48 volts DC. Its robust design includes a cover with wing screws for easy, tool-free installation, ensuring compliance with ABYC standards. The busbar accepts a wide range of wire sizes, from 8 AWG to 4 AWG for input and 16 AWG to 10 AWG for load connections, making it versatile for various wiring configurations. The inclusion of four write-on circuit labels allows for clear circuit identification, aiding in maintenance and troubleshooting. The busbar’s nesting capability with other water-resistant busbars and fuse blocks optimizes space in confined areas, streamlining wiring layouts. Its design is ideal for positive distribution and the collection of negative or AC ground circuits, especially in environments where water resistance is critical. The package includes the busbar and an instruction manual, providing everything needed for straightforward installation and operation. This product is sold individually, offering a reliable solution for marine, RV, or other harsh environment electrical systems.
Features:
Accepts a wide range of wire sizes including 8 AWG to 4 AWG for input and 16 AWG to 10 AWG for load connections
Includes three wire plugs to maintain water-resistant rating when fewer than four wires are used
Nests with other water-resistant 100A busbars and fuse blocks for space-efficient wiring
Designed for positive distribution and collection of negative or AC ground circuits
Meets ABYC and USCG insulation requirements for marine safety
Tin-plated copper bus and fuse clips resist corrosion for long-term reliability
Includes four write-on circuit labels for clear circuit identification
Wing screws enable tool-free cover installation to meet ABYC standards
