Blue Sea Systems 4304 WeatherDeck Water-Resistant Fuse Panel with 4 Positions, Gray

WeatherDeck Water Resistant Fuse Panel

PN: 4304

Color: Gray

Features:

• Panel front rated IP67 when properly mounted with watertight mounting gasket
• IP67 protected against immersion up to 1 meter for 30 minutes
• Designed for flybridge and open cockpit applications
• Independent label back lighting circuit for remote switching and dimming
• Each panel can be mounted in four different orientations
• Integrated ATO/ATC fuse based circuit protection
• Bicolored LEDs illuminate circuit labels to quickly identify OFF (Red), ON (Green), or Blown (No Color) circuits. No lights in any position likely indicate there is no power to the panel.

Specifications:

• Weatherproof: Waterproof
• Positions: 4
• Nominal Voltage: 12v DC
• Circuit Protection: Fuse
• Maximum Amperage: 15A @ 12v DC (per circuit)
• Panel Cumulative Rating: 60A
• Backlit Label: Bicolored LED
• Backlighting Amperage: 10mA/illuminated Circuit
• Backlighting Voltage: 12v DC
• Height: 4.3"
• Width: 3.88"
• Depth: 2.5"

Included:

• (4) 4138 WeatherDeck Toggle Switch Boot - Black
• (4) 4150 WeatherDeck Toggle Switch SPST - ON-OFF
• (1) 4215 Waterproof DC Label Kit - 30 Black Square Labels V1
• (4) 5242 ATO/ATC Fuse - 15 Amp

WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

The Blue Sea Systems 4304 WeatherDeck Fuse Panel offers reliable power management for marine applications, especially designed for flybridge and open cockpit setups. Constructed with a durable, waterproof design, this panel is rated IP67 when properly mounted with the included watertight gasket, providing protection against immersion up to 1 meter for 30 minutes. Its rugged construction ensures safe operation in harsh marine environments, making it an ideal choice for boaters seeking a dependable electrical solution. The panel features four switch positions, supporting a maximum of 15 amps per circuit at 12 volts DC, with a total capacity of 60 amps. Each circuit is protected by integrated ATO/ATC fuse holders, simplifying maintenance and enhancing safety. The backlit labels utilize bicolored LEDs that illuminate red for OFF, green for ON, and no color for blown fuses, allowing quick circuit status identification even in low-light conditions. The panel’s versatile design allows it to be mounted in four different orientations, providing flexible installation options to suit your vessel's layout. Included with the fuse panel are weatherproof toggle switch boots, SPST ON-OFF switches, waterproof label kits, and fuse components, ensuring a comprehensive setup for your marine electrical system. Crafted from high-quality materials and engineered for durability, the Blue Sea 4304 WeatherDeck Fuse Panel ensures your electrical circuits remain protected and easily manageable in challenging marine environments. Its compact design and thoughtful features make it an essential component for boat owners looking to optimize their electrical system's safety and reliability.

Features:

• IP67 rated waterproof design with watertight mounting gasket

• Protected against immersion up to 1 meter for 30 minutes

• Designed for marine environments like flybridges and open cockpits

• Independent label back lighting circuit with remote switching and dimming

• Mountable in four different orientations for flexible installation

• Integrated ATO/ATC fuse-based circuit protection

• Bicolored LEDs illuminate labels for OFF (Red), ON (Green), or Blown (No Color)

• Supports 12V DC systems with a maximum of 15 amps per circuit

• Total panel capacity of 60 amps for multiple circuits

• Includes waterproof toggle switch boots, switches, labels, and fuses for comprehensive setup
