Blue Sea Systems 7046 187-Series 120 Amp Thermal Circuit Breaker - Panel Mount

• Combines switching and circuit protection into a single device

• All components meet SAE J1171 external ignition protection requirements

• Clear, single lever operation

• Trip Free design cannot be held ON during fault current condition

• Waterproof

• Recessed mounting holes for clean appearance

• Self-trimming case eliminates the need for mounting panels or trim bezels

• Round case permits easy installation with standard sized hole saw

• Large clearance around terminal studs accept heavy gauge wire lugs

• Robust 5/16 terminals provide high torque connections

• Large lever with vertical/horizontal orientation provides indication of trip status

• Ignition protected - safe for installation aboard gasoline powered boats

WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

The Blue Sea Systems 7046 187-Series thermal circuit breaker provides reliable overcurrent protection with a 120 Amp rating, ideal for marine and industrial applications. This panel-mounted device combines switching and circuit protection into a single, space-efficient unit, simplifying wiring and maintenance. Constructed with a thermoset polyester case, it meets SAE J1171 external ignition protection standards, ensuring safe operation aboard gasoline-powered boats. The clear, single-lever operation allows for quick manual reset and status checks, while the trip-free design prevents the switch from being held in the ON position during fault conditions, enhancing safety and system reliability. Waterproofing ensures durability in harsh environments, and recessed mounting holes give a clean appearance with minimal panel intrusion. The round case facilitates easy installation using a standard hole saw, and the large clearance around terminal studs accommodates heavy gauge wire lugs for secure connections. Robust 5/16-inch terminals allow for high-torque tightening, ensuring good electrical contact. The large lever can be oriented vertically or horizontally, providing visual indication of trip status at a glance, which simplifies troubleshooting and system monitoring. This circuit breaker is designed for versatile use, with an operating temperature range from -25°C to +82°C, making it suitable for a variety of demanding conditions. Its high interrupt ratings—up to 5,000 Amperes at 12 Volts DC—ensure it can safely handle large fault currents, protecting your electrical system from damage. Whether used in marine, RV, or industrial applications, this breaker offers durable, reliable circuit protection with easy installation and maintenance.

Features:

• Combines switching and circuit protection into a single device

• Meets SAE J1171 external ignition protection requirements

• Clear, single lever operation for easy manual reset

• Trip-free design prevents holding ON during faults

• Waterproof construction for harsh environments

• Recessed mounting holes for a clean appearance

• Self-trimming case simplifies installation without panels or bezels

• Round case allows installation with standard hole saw

• Large clearance around terminal studs for heavy gauge wire lugs

• Robust 5/16-inch terminals provide high torque connections

• Large lever with vertical/horizontal orientation indicating trip status

• Ignition protected for safe installation on gasoline-powered boats

• Operates within -25°C to +82°C temperature range

• High interrupt ratings up to 5,000 Amperes at 12 Volts DC
