Blue Sea Systems 7049 200 Amp Panel Mount 187 Series Circuit Breaker

• Combines switching and circuit protection into a single device*

• Clear, single lever operation

• "Trip Free" design cannot be held "ON" during fault current condition

• Waterproof

• Recessed mounting holes for clean appearance

• Large Clearance around terminal studs accecpt heavy gauge wire lugs

• Robust 5/16 M8 terminals provide high torque connections

• Large lever with vertical/horizontal orientation provides indication of trip status

• Ignition protected - Safe for installation aboard gasoline powered boats

• Interrupt Rating - 5,000 A@12V DC, 3,000A@24V DC, 1,500A@42V DC

• Maximum Voltage Rating - 48 Volts DC

• Operating Temperature Range - -40xC to 85xC

• Circuit Breaker Type - Thermally responsive bi-metal blade

• Circuit Breaker Class - Type III - switchable/manual reset - trip free

• Terminal Stud Size - 5/16"-18

• Terminal Stud Torque - 75 in-lb

• Mounting Holes - Accept #10 (M5) Screw

• Weight Lb (Kg) - 0.50 (0.23)

• Case Material - Thermoset Polyester

WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

The Blue Sea Systems 7049 200 Amp Panel Mount 187 Series Circuit Breaker offers reliable circuit protection combined with switching functionality in a compact, waterproof design. Engineered for demanding applications, this circuit breaker features a clear, single-lever operation that allows for easy control and status indication. Its "Trip Free" design ensures that the breaker cannot be held in the "ON" position during a fault current, providing enhanced safety and protection. The recessed mounting holes contribute to a clean appearance, while the large clearance around terminal studs accommodates heavy gauge wire lugs for secure connections. Robust 5/16" M8 terminals enable high torque connections, ensuring reliable electrical contact even under vibration or heavy loads. The large lever, which can be oriented vertically or horizontally, provides an intuitive indication of the trip status, simplifying troubleshooting and system monitoring. Approved for use aboard gasoline-powered boats, this ignition-protected breaker adheres to safety standards, ensuring safe operation in marine environments.
Constructed with a thermoset polyester case, the circuit breaker is rated for an interrupt current of up to 5,000 amps at 12V DC and 3,000 amps at 24V DC, with a maximum voltage rating of 48 volts DC. Its thermally responsive bi-metal blade design ensures precise protection across a wide operating temperature range from -40°C to 85°C. The breaker’s terminal studs are sized at 5/16"-18, with a torque requirement of 75 in-lb, offering a secure and durable connection. Mounting is straightforward with acceptance for #10 (M5) screws, making installation flexible in various panel configurations. Weighing approximately 0.50 pounds (0.23 kg), this breaker combines durability with ease of use for both marine and industrial applications.
Note: This product may contain chemicals such as di(2-ethylhexyl)phthalate (DEHP), which is recognized in California for potential health risks. For more information, visit P65Warnings.ca.gov.

Features:

• Combines switching and circuit protection into a single device

• Clear, single lever operation for easy control

• Trip Free design prevents holding the breaker "ON" during faults

• Waterproof construction suitable for harsh environments

• Recessed mounting holes for a clean appearance

• Large clearance around terminal studs for heavy gauge wire lugs

• Robust 5/16"-18 terminals for high torque connections

• Large lever with vertical/horizontal orientation shows trip status

• Ignition protected and safe for marine engine installations
