Blue Sea Systems 7491 360 Panel Double Pole Double Throw (DPDT) Rocker Switch – ON-ON

360 Panel - Rocker Switch DPDT - ON-ON

The 360 Panel System uses an open frame to mount a broad selection of modules, allowing multiple functions to be combined in a single panel.

This innovative design offers a wide choice of panel features, can accommodate future changes and permits rapid assembly. With options ranging from battery management to source selection, the 360 Panel System provides unmatched design flexibility.

For use in 360 panels in the following modules: Gauge, DC Push Button + Switch, and DC Battery Management

Specifications:

• Action*: ON-ON

• Pole/Throw**: DPDT

• Maximum Amperage***:8A @ 125V AC / 5A @ 12V DC / 5A @ 24V DC / 4A @ 250V AC

• Terminal Type: Wire Leads

• Terminal Size: 6.00" (152.4mm)

• Weight:0.08lb (0.04kg)

*Action () = Momentary ON

**Pole/Throw:
SPST - Single Pole/Single Throw
SPDT - Single Pole/Double Throw
DPST - Double Pole/Single Throw
DPDT - Double Pole/Double Throw

***Maximum Amperage - Maximum amperage ratings are dependent on use of appropriately sized fuses and wire for a given application.

WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

The Blue Sea Systems 7491 360 Panel System features an open frame design that allows for versatile module mounting, making it ideal for complex electrical setups. This innovative panel system supports a wide range of functions, including battery management and source selection, providing users with flexible and expandable control options. Its modular approach simplifies installation and future modifications, making it suitable for various marine, automotive, and industrial applications.

Designed with a robust DPDT (Double Pole Double Throw) mechanism, this rocker switch delivers reliable performance with an action of ON-ON, enabling seamless switching between two circuits without interruption. The switch features wire leads for straightforward wiring connections and supports a maximum of 8 amps at 125 volts AC or 5 amps at 12 and 24 volts DC, ensuring compatibility with many electrical systems. Its compact design and lightweight construction make it easy to integrate into your control panel without adding significant bulk or weight.

Ideal for use in 360 panels that accommodate gauges, DC push buttons, switches, and battery management modules, the Blue Sea Systems 7491 switch provides durable operation and flexible installation options. The terminal size of 6 inches allows for easy wiring, while the overall design emphasizes reliability and safety. This switch is suitable for applications requiring dependable switching capabilities and can be used with appropriately sized fuses and wiring for optimal performance. Note that this product contains chemicals that may pose health risks, and proper handling is advised.

Features:

• Open frame design for versatile module mounting in 360 panels

• Double Pole Double Throw (DPDT) switch for reliable circuit switching

• ON-ON action for seamless circuit toggling

• Supports up to 8A at 125V AC and 5A at 12V/24V DC

• Wire lead terminal type with 6-inch leads for easy wiring

• Compact and lightweight construction for easy integration

• Suitable for battery management, source selection, and gauge modules

• Robust design for demanding electrical environments
