Blue Sea Systems 7492 360 Panel Double Pole Double Throw Rocker Switch (ON-OFF-ON)

360 Panel - Rocker Switch DPDT - ON-OFF-ON

For use in 360 panels in the following modules: Gauge, DC Push Button + Switch, and DC Battery Management

The 360 Panel System uses an open frame to mount a broad selection of modules, allowing multiple functions to be combined in a single panel.

This innovative design offers a wide choice of panel features, can accommodate future changes and permits rapid assembly. With options ranging from battery management to source selection, the 360 Panel System provides unmatched design flexibility.

Specifications:

• Action*: ON-OFF-ON

• Pole/Throw**: DPDT

• Maximum Amperage***:8A @ 125V AC / 5A @ 12V DC / 5A @ 24V DC / 4A @ 250V AC

• Terminal Type: Wire Leads

• Terminal Size: 6.00" (152.4mm)

• Weight:0.08lb (0.04kg)

*Action () = Momentary ON

**Pole/Throw:
SPST - Single Pole/Single Throw
SPDT - Single Pole/Double Throw
DPST - Double Pole/Single Throw
DPDT - Double Pole/Double Throw

***Maximum Amperage - Maximum amperage ratings are dependent on use of appropriately sized fuses and wire for a given application.

WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

The Blue Sea Systems 7492 360 Panel features a versatile DPDT (Double Pole Double Throw) rocker switch designed for use in 360 panels across various modules such as gauge systems, DC push buttons, and battery management units. Its open-frame design allows for quick assembly and flexible integration, making it ideal for applications where multiple functions need to be combined in a compact panel. This innovative system supports future modifications and offers a broad range of panel features, enhancing the adaptability of your electrical setup. The switch provides reliable operation with an ON-OFF-ON action, enabling precise control over connected circuits. Its wire lead terminals simplify wiring and installation, ensuring a secure connection. Suitable for applications with up to 8 amps at 125V AC or 5 amps at 12V and 24V DC, this switch balances performance with safety, provided appropriate fusing and wiring are used. The switch's compact size and lightweight design make it suitable for space-constrained environments, while its robust construction assures durability in various conditions. The 7492 switch is an essential component for electrical panels demanding reliable switching solutions with flexible configurations. Please note that this product contains chemicals known to the State of California to cause reproductive harm, and proper handling is recommended. For more information, visit P65Warnings.ca.gov.

Features:

• Action: ON-OFF-ON momentary switch for versatile control

• Pole/Throw: Double Pole Double Throw (DPDT) for complex switching needs

• Maximum Amperage: 8A at 125V AC, 5A at 12V and 24V DC for reliable performance

• Terminal Type: Wire leads for straightforward wiring

• Terminal Size: 6 inches long for flexible installation
