Blue Sea Systems WeatherDeck 4308 Water-Resistant Fuse Panel, 8 Positions, Gray

WeatherDeck Water Resistant Fuse Panel

PN: 4308

Color: Gray

Features:

• Panel front rated IP67 when properly mounted with watertight mounting gasket
• IP67 protected against immersion up to 1 meter for 30 minutes
• Designed for flybridge and open cockpit applications
• Independent label back lighting circuit for remote switching and dimming
• Each panel can be mounted in four different orientations
• Integrated ATO/ATC fuse based circuit protection
• Bicolored LEDs illuminate circuit labels to quickly identify OFF (Red), ON (Green), or Blown (No Color) circuits. No lights in any position likely indicate there is no power to the panel.

Specifications:

• Weatherproof: Waterproof
• Positions: 8
• Nominal Voltage: 12v DC
• Circuit Protection: Fuse
• Maximum Amperage: 15A @ 12v DC (per circuit)
• Panel Cumulative Rating: 100A
• Backlit Label: Bicolored LED
• Backlighting Amperage: 10mA/illuminated Circuit
• Backlighting Voltage: 12v DC
• Height: 7.7"
• Width: 3.88"
• Depth: 2.5"

Included:

• (8) 4138 WeatherDeck Toggle Switch Boot - Black
• (8) 4150 WeatherDeck Toggle Switch SPST - ON-OFF
• (1) 4215 Waterproof DC Label Kit - 30 Black Square Labels V1
• (8) 5242 ATO/ATC Fuse - 15 Amp

WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

The Blue Sea Systems WeatherDeck 4308 fuse panel offers reliable water resistance for marine environments, making it ideal for flybridge and open cockpit applications. Designed with an IP67 front rating, it is protected against water immersion up to 1 meter for 30 minutes when properly mounted with the watertight gasket, ensuring durability in harsh weather conditions. This panel features eight circuit positions, each protected by integrated ATO/ATC fuses rated at 15 amps, providing robust circuit protection for your boat’s electrical system. The fuse panel supports a maximum cumulative load of 100 amps at 12 volts DC and is suitable for various marine electrical setups.
The WeatherDeck fuse panel includes backlit circuit labels with bicolored LEDs, allowing quick circuit status identification: red for OFF, green for ON, and no color for blown fuses. The backlighting consumes only 10mA per illuminated circuit and operates at 12 volts DC. The panel's versatile design permits four different mounting orientations to accommodate various installation needs. Its compact dimensions ensure it fits seamlessly into tight spaces while maintaining accessibility and functionality.
Included with the fuse panel are weatherproof toggle switch boots, SPST ON-OFF toggle switches, black square labels for circuit identification, and 15-amp ATO/ATC fuses, providing everything needed for immediate installation and operation. This product is constructed from high-quality materials to withstand marine environments and is built for easy maintenance and troubleshooting. Ensure your boat’s electrical system remains protected and organized with the Blue Sea Systems WeatherDeck fuse panel, a dependable solution for marine power management.

Features:

• Panel front rated IP67 for waterproof protection when properly mounted with gasket

• Protected against immersion up to 1 meter for 30 minutes

• Designed specifically for flybridge and open cockpit applications

• Independent label backlighting circuit with remote switching and dimming capability

• Supports four different mounting orientations for flexible installation

• Integrated ATO/ATC fuse-based circuit protection for each of the eight positions

• Bicolored LED illumination for circuit labels indicating OFF, ON, or Blown status

• Maximum current per circuit: 15A at 12V DC

• Total panel rating: 100A

• Includes weatherproof toggle switch boots, SPST switches, circuit labels, and fuses
