Bluewater 22mm Inrush Push Button Switch with Blue/Red LED - Marine Waterproof Momentary Switch Body Only

22mm Inrush Push Button Switch Momentary - Blue/Red LED - Switch Body Only

The switch is the core of your control system. Built marine tough with inrush protection and waterproof sealing for reliable performance.

Upgrade your marine switch panel with the 9059 Series 22mm Inrush Protection Switch. Built for heavy-duty marine applications, this switch handles high surge currents with ease - perfect for pumps, motors, and other demanding onboard equipment.

Built for Harsh Marine Conditions:

• Encased in corrosion-resistant SS316 stainless steel
• Rated IP69K waterproof with Bluewaters proprietary Deutsch-style connectors
• Resistant to salt spray, heat, vibration, and shock

Easy to See and Control:

• Blue LED backlighting for night visibility
• LED shifts to bright red when activeinstant confirmation of pump or device status
• Fully detachable actuator for customization of style and function

Reliable Power Handling:

• Rated for 20 amps on a single channel
• Rated for 10 amps per channel in dual-channel use
• Impact-resistant and designed for long-lasting performance

Why Choose the 9059 Switch for Your Marine Switch Panel

This inrush protection switch combines rugged durability with smart design. It installs easily, provides dependable control, and ensures your marine switch panel remains reliable in all conditions.

When you are on the water, trust the 9059 Series to keep your critical systems running smoothly and safely.

Specifications:

• Switch Rating: 20A/12-24VDC
• Switch Contacts: 1 NO, 1 NC | 2 NO, 2 NC
• Mechanical Life: 50,000 Cycles
• Electrical Life: 10,000 Cycles
• Dimensions: View Dimensional Drawings
• Material: Nickel Plated Brass/ Stainless Steel
• LED Color: Blue/Green/Red

Installation:

Drill a 22mm hole into any material up to 6mm thick. Connect the 3 contacts for the button (color coded for your safety and convenience). Lastly connect the 2 contacts for the LED.

Upgrade your marine control panel with the Bluewater 9059-2113 22mm inrush protection push button switch. Crafted to withstand harsh marine environments, this switch features a durable stainless steel body and waterproof sealing rated at IP69K, ensuring reliable operation even in salt spray, high humidity, and vibration. Its robust construction combined with inrush protection makes it ideal for controlling pumps, motors, and other onboard equipment that require high surge capacity. The switch's corrosion-resistant design guarantees longevity and consistent performance across demanding conditions, providing peace of mind for critical marine applications.

Designed for easy visibility and operation, the switch includes a blue LED backlight for night-time control, which shifts to bright red when active, offering instant status confirmation. The fully detachable actuator allows customization to suit different control preferences or aesthetic requirements. Rated for 20 amps on a single channel and 10 amps per channel in dual configurations, this switch is built for heavy-duty use. Its impact-resistant design ensures long-lasting performance, making it a reliable choice for marine environments.

Installation is straightforward—simply drill a 22mm hole into materials up to 0.24 inches thick, connect the color-coded contacts for the button and LED, and secure. The switch features a mechanical life of 50,000 cycles and an electrical life of 10,000 cycles, emphasizing durability and dependable operation over time. Constructed from nickel-plated brass and stainless steel, it combines strength with corrosion resistance. The switch's versatile contact configurations (normally open, normally closed, or both) accommodate various control needs, while its LED options include blue, green, and red for easy identification.

Whether upgrading an existing panel or installing a new control system on your vessel, the Bluewater 9059-2113 switch offers a rugged, reliable, and easily customizable solution. Its compact size and marine-grade features ensure it performs seamlessly in demanding conditions, helping keep your critical systems running smoothly and safely at sea.

Features:

• Corrosion-resistant stainless steel body suitable for marine environments

• Waterproof sealing rated at IP69K for reliable operation in harsh conditions

• Blue LED backlighting for night visibility with active red indicator for status confirmation

• Rated for 20 amps on a single channel and 10 amps per channel in dual-channel configuration

• Impact-resistant construction designed for long-term durability

• Easy installation with a standard 22mm mounting hole and color-coded contacts

• Detachable actuator for customization of style and function

• Built with inrush protection for handling high surge currents safely

• Mechanical life expectancy of 50,000 cycles and electrical life of 10,000 cycles

• Versatile contact configurations including 1 NO, 1 NC, or 2 NO, 2 NC
