Bluewater Enterprises 9059-7002 22mm 2N1 Double Momentary Rocker Switch, +12V

Bluewater 22mm 2N1 Rocker Switch, Double Momentary (On)-Off-(On), +12V

The Bluewater Enterprises 9059-7002 is a 22mm 2N1 rocker switch designed to provide momentary up/down control from a single mounting cutout. Its double momentary (On)-Off-(On) function activates when the top or bottom of the rocker is pressed and turns off when released. The switch uses +12V switching for control applications including trim tabs, jack plates, windshield vents and antenna lifts.

Integrated LED feedback provides a blue backlight, green output 1 indication and red output 2 indication. The switch supports 10A per channel and 20A combined at 12VDC, making it suitable for applications requiring dual switched outputs. Its nickel-plated brass and SS316 stainless steel construction is designed for demanding environments.

With an IP69K protection rating, the sealed switch is built to withstand salt spray, washdowns and submersion. It is rated for 50,000 mechanical cycles and 10,000 electrical cycles. Installation requires a 22mm mounting hole and a Bluewater 22mm Deutsch-style harness.

This switch does not include internal reverse polarity. When driving linear actuator motors, use a reverse polarity relay module. The compatible 22mm harness is sold separately.

Features:

• Function: Double momentary (On)-Off-(On) rocker operation; press the top or bottom for momentary on and release to turn off
• Control: Provides +12V switched up/down control from a single 22mm mounting cutout
• Applications: Suitable for trim tabs, jack plates, windshield vents and antenna lifts
• LED Feedback: Blue backlight with green output 1 and red output 2 indicators
• Dual Outputs: Supports 10A per channel and 20A combined at 12VDC
• Protection: IP69K-rated sealed construction for salt spray, washdowns and submersion
• Construction: Nickel-plated brass and SS316 stainless steel materials
• Service Life: Rated for 50,000 mechanical cycles and 10,000 electrical cycles
• Installation: Requires a 22mm mounting hole and a Bluewater 22mm Deutsch-style harness
• Motor Control Note: No internal reverse polarity; use a reverse polarity relay module when driving linear actuator motors
