Bluewater Enterprises 9059-7015 22mm 2N1 Rocker Dimmer Switch with Built-In PWM

Bluewater 22mm 2N1 Rocker Dimmer Switch, Built-In PWM, +12V

The Bluewater Enterprises 9059-7015 is a 22mm 2N1 rocker dimmer switch designed for smooth, precise control of cabin, cockpit, and accent lighting. Its rocker actuator lets you press and hold the top to brighten, press and hold the bottom to dim, and release to stop at the desired level.

Built-in pulse-width modulation eliminates the need for an external dimmer and supports dimming for both LED and incandescent lights. Pressing both sides together provides on/off control, allowing the connected lights to be turned off and back on. The switch can also dim the blue backlights of other Bluewater switches installed in the same panel.

The sealed SS316 stainless steel body is rated IP69K for resistance to salt spray, washdowns, and submersion. The switch provides a +12V switched output and is rated for 8A at 12VDC or 4A at 24VDC. Its listed mechanical life is 50,000 cycles, while its electrical life is 10,000 cycles.

Installation requires a 22mm mounting hole and connection to a Bluewater 22mm Deutsch-style harness. The specified harness, part number 9053-3914, is sold separately. The switch uses nickel-plated brass and SS316 stainless steel construction.

Features:

• Rocker Dimming: Press and hold the top to brighten, press and hold the bottom to dim, and release to stop.
• On/Off Toggle: Press both sides together to turn the connected lights off and back on.
• Built-In PWM: Dims LED and incandescent lights without requiring an external dimmer.
• Backlight Control: Dims the blue backlights of other Bluewater switches in the same panel.
• Marine Sealing: IP69K protection with a sealed SS316 stainless steel body.
• Electrical Rating: +12V switched output with an 8A rating at 12VDC or 4A rating at 24VDC.
• Construction: Nickel-plated brass and SS316 stainless steel materials.
• Service Life: Rated for 50,000 mechanical cycles and 10,000 electrical cycles.
• Installation: Requires a 22mm mounting hole and a Bluewater 22mm Deutsch-style harness.
