Cradlepoint S700-C4D Semi-Ruggedized 4G LTE IoT Modem/Wireless Router, TBA5-0700C4D-NN

CradlePoint S700-C4D Wi-Fi 6 IEEE 802.11ax 2 SIM Ethernet, Cellular Modem/Wireless Router

The Cradlepoint S700-C4D semi-ruggedized modem/wireless router, part number TBA5-0700C4D-NN, delivers secure, cloud-managed connectivity for industrial IoT, portable networking, surveillance, digital signage, and fixed-location applications. Designed for demanding deployments, the S700 combines embedded 4G LTE connectivity with wired networking, concurrent dual-band Wi-Fi 6, configurable GPIO, and active GNSS/GPS support. Its aluminum housing and DIN rail mounting capability make it suitable for field installations, embedded systems, and light industrial environments.

With Cradlepoint NetCloud Service for IoT, the S700-C4D enables centralized management for deployments ranging from individual sites to large-scale router fleets. Administrators can define policies, monitor device status, review analytics, troubleshoot remotely, and apply software and firmware updates through a cloud-based platform. Dual SIM support helps maintain reliable cellular connectivity, while Cat 4 LTE provides dependable broadband access for connected equipment and distributed IoT networks.

The S700 supports encrypted routing technologies including DMVPN, IPsec, and GRE for secure site-to-site and remote connectivity. Cradlepoint NetCloud Exchange Secure Connect and zero trust networking capabilities help protect connected devices with encrypted tunnels, micro-segmentation, and policy-based access. Authorized users and third parties can securely access IoT equipment for monitoring and maintenance without exposing unnecessary network resources. NetCloud integrations, SDK tools, APIs, and Microsoft Azure IoT Central compatibility provide options for extending and integrating IoT operations.

This Cradlepoint S700-C4D package includes the router, GPIO and power cable, 12 VDC power supply, cellular antennas, and Wi-Fi antennas. The semi-ruggedized design supports operation in environments affected by vibration and temperature variation, while REACH compliance and a lifetime limited warranty support long-term deployment planning. It is an effective choice for organizations seeking secure, scalable, and centrally managed LTE connectivity for distributed IoT assets.

Features:

• Centralized cloud management for defining policies, monitoring deployments, troubleshooting, analytics, and updates
• Embedded Cat 4 4G LTE modem with dual SIM support for reliable cellular connectivity
• Concurrent dual-band Wi-Fi 6 for expanded wireless coverage and IoT connectivity
• Semi-ruggedized aluminum housing designed to withstand vibration and temperature extremes
• DIN rail-mountable form factor for industrial, fixed, portable, and embedded installations
• Configurable GPIO ports and NetCloud integrations for industrial IoT applications
• Active GNSS/GPS support for asset tracking and mobile IoT deployments
• Encrypted routing support for DMVPN, IPsec, GRE, and other VPN tunneling technologies
• NetCloud SDK and API support for customization and integration
• Zero trust networking capabilities with secure, policy-based access for connected devices
• Includes GPIO and power cable, 12 VDC power supply, cellular antennas, and Wi-Fi antennas
