Two Independent ACRs in One Device reduce installation space and time. Significantly lowers the out-of-state current draw.
Features:
Eliminates Dead Start Batteries by sharing charge sources with all batteries and isolating batteries when no charge sources are present
Simple Robust Installation:Integrated sealed plug eliminates corrosion, includes DT04 harness. A single device reduces installation time, space, cost, and points of potential failure
An additional low-amp output can be used to report device status remotely.
Ultra Low Off-State Current: Compare two typical ACRs (20 mA) vs Dual ACR @ 1.3 mA
Adjustable Off-Voltage for Auxiliary Battery Priority provides the ability to share start battery energy for auxiliary without risking engine starting ability.
Start/Engine Isolation input option for ensuring sensitive electronics do not experience voltage sags and spikes from the cranking event.
Start Assist input option to ensure maximum cranking amps available when necessary.
4 Year Industry-Leading Warranty
The Egis Mobile Electric Triple Battery Advanced Automatic Charging Relay (ACR) is a robust and efficient solution designed to optimize your vehicle's battery management. Featuring two independent ACRs integrated into a single compact unit, this device significantly reduces installation space and time while ensuring reliable battery isolation and charging. Its advanced design helps prevent dead start batteries by sharing charge sources among all batteries and isolating them when no charge is available, promoting longer battery life and consistent performance. The sealed construction, high-temperature resistant materials, and thermal overload shutdown protection allow for versatile mounting options in demanding environments, making it suitable for various vehicle applications.
The ACR includes an integrated sealed plug with a DT04 harness, simplifying installation and reducing points of potential failure. An additional low-amp output allows remote reporting of device status, providing greater system monitoring capabilities. Its ultra-low off-state current (approximately 1.3 mA compared to typical 20 mA ACRs) minimizes power drain during vehicle off periods, enhancing overall electrical efficiency. Adjustable off-voltage settings enable prioritization of auxiliary battery charging without compromising engine start reliability, ensuring the vehicle remains ready to operate. The device also offers start/engine isolation and start assist inputs, safeguarding sensitive electronics and maximizing cranking power when needed. Backed by a 4-year industry-leading warranty, the Egis Triple Battery ACR delivers dependable, long-lasting performance for demanding vehicle setups.
Features:
Eliminates dead start batteries by sharing charge sources and isolating batteries when no charge is present
Simplified, robust installation with integrated sealed plug and DT04 harness to reduce time, space, and potential failure points
Additional low-amp output for remote device status reporting
Sealed unit with high-temperature materials and thermal overload protection for versatile mounting
Ultra-low off-state current of approximately 1.3 mA, reducing power drain during vehicle off periods
Adjustable off-voltage for auxiliary battery priority to maintain engine start capability
Start/engine isolation input to protect sensitive electronics from voltage sags and spikes
Start assist input to maximize cranking amps when necessary
Four-year industry-leading warranty for reliable performance
