Egis Mobile Electric Triple Battery Advanced Automatic Charging Relay (ACR) - 24V

Triple Battery Advanced Automatic Charging Relay (ACR) - 24V

Two Independent ACRs in One Device reduce installation space and time. Significantly lowers the out-of-state current draw.

Features:

• Eliminates Dead Start Batteries by sharing charge sources with all batteries and isolating batteries when no charge sources are present
• Simple Robust Installation:Integrated sealed plug eliminates corrosion, includes DT04 harness. A single device reduces installation time, space, cost, and points of potential failure
• An additional low-amp output can be used to report device status remotely.
• Bullet-proof Construction: Sealed unit, high-temperature materials allow mounting anywhere. Integrated thermal overload shutdown protection
• Ultra Low Off-State Current: Compare two typical ACRs (20 mA) vs Dual ACR @ 1.3 mA
• Adjustable Off-Voltage for Auxiliary Battery Priority provides the ability to share start battery energy for auxiliary without risking engine starting ability.
• Start/Engine Isolation input option for ensuring sensitive electronics do not experience voltage sags and spikes from the cranking event.
• Start Assist input option to ensure maximum cranking amps available when necessary.
• 4 Year Industry-Leading Warranty

The Egis Mobile Electric Part Number 7612-24 is a high-performance triple battery automatic charging relay designed for efficient and reliable power management in 24V systems. This advanced device incorporates two independent automatic charging relays within a single unit, significantly reducing installation space and time while minimizing out-of-state current draw for optimized battery performance. Its robust construction features a sealed design with high-temperature materials, allowing versatile mounting options without concern for corrosion or thermal issues. The integrated thermal overload shutdown protection ensures durability and reliability in demanding environments.
Designed for simplicity and efficiency, the Egis 7612-24 includes an integrated sealed plug and DT04 harness, reducing installation points and potential failure sources. The relay's low-amp auxiliary output provides remote status reporting, enhancing system monitoring capabilities. An adjustable off-voltage setting allows users to prioritize auxiliary batteries without compromising the engine’s start power, ensuring optimal energy sharing among batteries. The device also offers start/engine isolation inputs to protect sensitive electronics from voltage sags during cranking, and start assist inputs to maximize cranking amps when needed. An ultra-low off-state current of just 1.3 mA compared to typical 20 mA units ensures minimal power drain when the relay is inactive. With a four-year industry-leading warranty, the Egis 7612-24 delivers dependable performance for professional automotive and RV applications, making it a vital component for complex battery systems requiring efficient charge management and enhanced reliability.

Features:

• Eliminates dead start batteries by sharing charge sources with all batteries and isolating batteries when no charge sources are present

• Simple, robust installation with integrated sealed plug and DT04 harness, reducing installation time, space, and potential failure points

• Additional low-amp output for remote device status reporting

• Sealed construction with high-temperature materials allowing mounting anywhere, including environments with thermal stress

• Ultra-low off-state current of 1.3 mA, significantly lower than typical 20 mA ACRs

• Adjustable off-voltage for auxiliary battery priority, enabling energy sharing without risking engine start ability

• Start/engine isolation input to prevent voltage sags and spikes from affecting sensitive electronics

• Start assist input to ensure maximum cranking amps when necessary

• Four-year industry-leading warranty for reliable long-term operation
