Furuno DT-800MSF Bronze TH NMEA2000 Depth And Temp

Furuno DT-800MSF Bronze TH NMEA2000 Depth And Temp

Furuno DT-800MSF Depth and temperature in one compact bronze housing

• Depth and temperature in one compact bronze housing


• Fast-response temperature sensor provides ±0.2°C (±0.1°F) accuracy


• Acoustic Window: Urethane

Designed with Airmar’s exclusive Broadband Ceramic Technology, the DT-800MSF's 235 kHz element improves resolution without sacrificing sensitivity. The higher power rating 100 W RMS provides spot-on depth readings in as little as 0.45 m (1.4’) of water and can reach depths up to 180 m (600’).

Weight
1.5 kg (3.4 lb)

Data Update Rate
1 per second

Minimum Sounding Depth
0.5 m (1.6’)

Maximum Sounding Depth
180 m (590’)

Pressure Rating
3 m (10’)

Pulse Rate
20,000 p/nm* (5.6 Hz per knot)—*p/nm = pulses per nautical mile

Smart Sensor Supply Voltage at 100% Sound Power Output
10 VDC to 25 VDC

Supply Current
40 mA S

tandard Cable Length
6m

NMEA 2000® Load Equivalency Number (LEN)
4
