Fusion Apollo MS-WB675 Hideaway Entertainment System

Fusion Apollo MS-WB675 Hideaway Entertainment System

Fusion Apollo MS-WB675 Marine Hideaway Stereo

Model: 010-02346-50

• Compact hideaway design means you don't sacrifice valuable dash space


• Separately control and customize up to four audio zones with Multi-ZoneTM Technology


• Integrated audio control with your Fusion wired remotes and compatible Garmin MFDs or smartwatches


• Connect via Ethernet to your wireless network router, Garmin MFD or ApolloTM Series stereo network to enjoy audio streaming and over-the-air updates via Wi-Fi(R) technology


• Stream premium quality audio from your favorite music apps via AirPlay(R) 2 software1 from Apple(R)

Amplify the moment, and maximize dash space with the Fusion Apollo WB675 marine hideaway stereo. This compact marine stereo offers Multi-ZoneTM Technology that controls up to four separate audio zones. While the Apollo WB675 stereo is small enough to fit most helm sizes or simply be tucked out of sight with its compact design, it still offers superior quality audio. Create custom audio profiles for each zone, and control the stereo with your Fusion wired remotes and compatible Garmin MFDs or smartwatches.

Specifications
Physical dimensions (HxWxD)5.1 x 5.1 in x 2.2 in (130 x 130 x 56 mm)

Weight
16.75 oz (475 g)

Power input
10.8-16 VDC

Operating temperature range
32-122 degrees F (0-50 degrees C)

Current (max)
15 A

NMEA 2000(R) network LEN
1 (50 mA)

BLUETOOTH(R) technology wireless range
Up to 30 feet (10 m)

ANT(R) connectivity wireless range
Up to 10 feet (3 m)

Wireless frequencies/protocols
BLUETOOTH 2.4 GHz @ +12 dBm nominal
ANT 2.4 GHz @ +7 dBm nominal

Compass-safe distance
5.9 in (150 mm)

Stereo Features

Built-in amplifier
Class-D (2 ohm stereo-stable)

Peak power
280 watts

Built-in amplifier
Class-D (2 ohm stereo-stable)

Rated power output (2 ohm)
43 watts RMS x 4 @ 14.4 V input < 10% THD

Rated power output (4 ohm)
26 watts RMS x 4 @ 14.4 V input < 10% THD

Built-in Digital Signal Processing
yes (with preconfigured DSP profiles)

PartyBusTM-Network capabilities
yes (wired)

Fusion-LinkTM control
yes (with MFD
