Garmin GC 245 Surface Mount Marine Camera - White for Enhanced Docking and Navigation

GC 245 Surface Mount Camera - White

BRING VISION TO YOUR HELM

Now theres a high-resolution marine camera that takes the stress out of docking your boat. Enhance proximity awareness and confidence in close quarters with the GC 245 surface-mount camera.

• Distance markers specific to your boat¹ and user defined guidance lines
• 1080p high-resolution output²
• See camera feeds in fisheye or standard view; birdseye view also available1
• Full integration on the Garmin marine network or Garmin Bluenet network

Guidance Lines

Set up your own guidance lines for more confidence avoiding obstacles in the marina.

Distance Markers

Use distance markers calibrated to your vessel by the boatbuilder so you know how far away you are from objects

Two Mounting Options

Installation is simple, and the camera can be mounted with the dome up or down.

Three Camera Views

Get the right perspective with FishEye and standard views with impressive low-light performance; GC 255 is also available with BirdsEye camera view¹.

Multiple Camera Feeds

See up to four camera feeds simultaneously on your compatible MFD; watch the video on networked chartplotters, or set it up on a custom combo page.

See What You Want

Take a closer look with digital zoom, or get a different perspective with digital pan.

In The Box:

• GC 245 surface mount camera
• GVA 10 with integrated power and network cables
• Network adapter cable (500 mm)
• Video coaxial cable (8 m)
• Mounting hardware
• Documentation

Specifications:

• Unit dimensions: 2.4 x 2.4 x 2.2 (6.1 x 6.1 x 5.1 cm)
• Weight: 3.25 oz (92 g)
• Hardwire power: 12V/24V
• Operating current: 300 mA at 12VDC; 200 mA at 24VDC
• Power consumption: 4.5 W
• Connection to chartplotter: IP
• Versatile mounting options: yes (ball-up or ball-down)
• Rugged housing: yes
• Setup: plug-and-play
• Water rating: IPX7
• Video resolution: 1920 x 1080 pixels²
• Video output: H.264 over GMN and BlueNet
• Images: Standard and reverse
• Selectable views: FishEye, standard, BirdsEye (OEM calibrated)
• Augmented reality features: Distance markers (OEM calibrated) and guidance lines (user setup)
• Viewing angle (H/V): 160H/90V
• Operating temperature: -20C to +60C
• Scanning system: progressive scan
• Day/night operation: RGB mode full-time

¹Professional calibration required

²1080p resolution available on select chartplotters only

Engineering enhancements are ongoing and may not be reflected in the pictures, videos and specifications.

The Garmin GC 245 Surface Mount Camera is designed to improve your boat handling experience by providing high-resolution video feeds that simplify docking and close-quarters maneuvering. This camera offers flexible installation options, allowing you to mount it with the dome facing up or down, ensuring optimal viewing angles for your specific needs. Built with a rugged, IPX7 water rating housing, it withstands harsh marine environments while delivering crisp 1080p video resolution. The camera's compatibility with Garmin’s marine network enables seamless integration with your existing chartplotters, providing real-time visuals directly on your displays.

Equipped with multiple viewing modes, the GC 245 offers FishEye, standard, and Birdseye perspectives, giving you versatile options to monitor your surroundings. The FishEye view provides a wide-angle perspective, ideal for tight docking spaces, while the Birdseye view offers an overhead angle to better assess obstacles. Digital zoom and pan functions allow you to focus on specific areas, enhancing situational awareness. The camera also features guidance lines and distance markers calibrated to your vessel, helping you judge distances accurately and avoid obstacles confidently. These features can be set up through professional calibration, ensuring precision tailored to your boat.

Installation is straightforward with versatile mounting options, allowing the camera to be installed with the dome up or down. The GC 245 supports multiple camera feeds—up to four simultaneously—displayed on compatible Multi-Function Displays (MFDs). This feature enables comprehensive monitoring of your vessel’s surroundings, whether watching networked chartplotters or custom page setups. The system's plug-and-play setup and low power consumption make it an efficient addition to your boat's electronics suite. Whether for day or night operation, the camera maintains full RGB imaging, ensuring visibility in various lighting conditions.

The Garmin GC 245 Surface Mount Camera comes with essential accessories, including network and coaxial cables, mounting hardware, and detailed documentation to facilitate installation. Its compact dimensions and lightweight design make it unobtrusive yet highly effective, providing peace of mind during docking, mooring, or navigating tight marina spaces. This camera is an essential tool for boaters seeking enhanced safety, confidence, and situational awareness on the water.

Features:

• High-resolution 1080p video output for clear imaging in marine environments

• Multiple viewing modes including FishEye, standard, and Birdseye perspectives

• Guidance lines and distance markers calibrated for your vessel to assist with obstacle avoidance

• Flexible installation with dome-up or dome-down mounting options

• Supports up to four camera feeds simultaneously on compatible MFDs

• Rugged, waterproof housing with IPX7 rating for durability in harsh conditions

• Digital zoom and pan features for focused views and improved situational awareness

• Plug-and-play setup with minimal wiring required for quick installation

• Versatile mounting options for optimal placement and viewing angles

• Day/night operation with full RGB imaging for visibility in various lighting conditions
