Garmin GC 255 Flush Mount Marine Camera with 1080p HD Video and Guidance Lines

GC 255 Flush Mount Camera

BRING VISION TO YOUR HELM

Take the stress out of docking your boat with a high-resolution marine camera. Enhance proximity awareness and confidence at the dock and in close quarters with the low-profile GC 255 flush-mount camera.

• Distance markers specific to your boat¹and user-defined guidance lines
• 1080p high-resolution output²
• Durable low-profile stainless steel finish
• See camera feeds in fisheye or standard view; birdseye view is also available¹
• Full integration on the Garmin marine network or Garmin Bluenet network

Guidance Lines

Set up your guidance lines for more confidence avoiding obstacles in the marina.

Distance Markers

Use distance markers calibrated to your vessel by the boatbuilder so you know how far away you are from objects

Rugged Installation

Thru-hull flush mounting ensures sleek and rugged installation.

Three Camera Views

Get the right perspective with FishEye and standard views with impressive low-light performance; GC 255 is also available with BirdsEye camera view¹.

Multiple Camera Feeds

See up to four camera feeds simultaneously on your compatible MFD; watch the video on networked chartplotters, or set it up on a custom combo page.

See What You Want

Take a closer look with digital zoom, or get a different perspective with digital pan.

In The Box:

• GC 255 flush mount camera
• GVA 10 with integrated power and network cables
• Network adapter cable (500 mm)
• Video coaxial cable (8 m)
• Mounting hardware
• Documentation

Specifications:

• Unit dimensions: 3.2 x 3.2 x 3.3 (8.1 x 8.1 x 8.38 cm), body; 3.2 x 3.2 x 0.95 (8.1 x 8.1 x 2.4 cm)
• Weight: 22.9 oz (650 g)
• Hardwire power: 12V/24V
• Operating current: 300 mA at 12VDC; 200 mA at 24VDC
• Power consumption: 4.5 W
• Connection to chartplotter: IP
• Versatile mounting options: thru-hull installation
• Rugged housing: yes (high impact)
• Install below rub rail: yes
• Setup: plug-and-play
• Water rating: IPX7
• Video resolution: 1920 x 1080 pixels²
• Video output: H.264 over GMN and BlueNet
• Images: Standard and reverse
• Selectable views: FishEye, standard, BirdsEye (OEM calibrated)
• Augmented reality features: Distance markers (OEM calibrated) and guidance lines (user setup)
• Viewing angle (H/V): 160H/90V
• Operating temperature: -20C to +60C
• Scanning system: progressive scan
• Day/night operation: RGB mode full-time

¹Professional calibration required

²1080p resolution available on select chartplotters only

Engineering enhancements are ongoing and may not be reflected in the pictures, videos and specifications.

Enhance your boating experience with the Garmin GC 255 flush-mount marine camera, designed for reliable and clear visibility during docking and maneuvering. Featuring a high-resolution 1080p video output, this camera provides crisp, detailed images that help you navigate tight marinas and close quarters confidently. Its low-profile stainless steel housing ensures durability and a sleek appearance, making it suitable for rugged marine environments. The GC 255 integrates seamlessly with Garmin marine networks, allowing you to view multiple camera feeds simultaneously on your compatible chartplotter or networked devices. Customizable features such as guidance lines and distance markers calibrated to your vessel enhance situational awareness and obstacle avoidance, reducing stress during docking procedures. The camera supports multiple viewing options, including FishEye, standard, and BirdsEye perspectives, with impressive low-light performance for day and night operation. Installation is straightforward with thru-hull flush mounting, and the rugged design ensures long-term performance even in harsh conditions. Additional features include digital zoom and pan capabilities for closer inspection and different viewing angles. This camera is ideal for boaters seeking a professional-grade solution to improve safety and confidence at the helm, with versatile mounting options and easy plug-and-play setup ensuring a seamless integration into your existing marine system.

Features:

• High-resolution 1080p video output for clear image quality

• Durable stainless steel low-profile housing for rugged marine environments

• Multiple camera views including FishEye, standard, and BirdsEye with OEM calibration

• Seamless integration with Garmin marine network and BlueNet network

• Guidance lines and distance markers calibrated to your vessel for obstacle avoidance

• Thru-hull flush mounting for sleek, low-profile installation

• Supports up to four camera feeds displayed simultaneously

• Digital zoom and pan features for detailed viewing

• Waterproof rating of IPX7 for reliable performance in marine conditions

• Operates in temperatures from -20°C to +60°C with full-time day/night mode
