Garmin GNA10 Jog Lever Adapter

Enhance Your Flight Control with Garmin GNA10 Jog Lever Adapter

Garmin GNA10 Jog Lever Adapter

Model: 010-13007-00

Use the Garmin GNA 10 to connect a jog lever to our Reactor 40 autopilots* on displacement hull boats. A jog lever is a rugged and simple steering control for work boats or trawlers. Adjust heading hold with the jog lever by pressing it right or left, or put the autopilot into the new Power Steering mode to move the rudder without autopilot guidance. The GNA 10 can also optionally connect to a button and LED light to allow switching between heading hold and standby**. Garmin does not supply the jog lever, button or LED light.

* The GNA 10 requires both a compatible Garmin autopilot and Garmin display

** The GNA 10 can also be used to interface a Reactor 40 autopilot with Jastram digital steering controls

The GNA 10 with jog lever is designed only for use on displacement hull power boats. It is not compatible with planing hull boats or sailboats.

Specifications

Cable length2.8 meters

Water rating
IPX7

NMEA output
NMEA 2000

NMEA 2000(R) LEN (Load Equivalency Number)
5 (250mA @ 9VDC)

Operating temperature
-20C to 75C

Supply voltage
Powered by NMEA 2000 bus, 9-32V

Supported Jog Levers
Kobelt 7170

Supported Button Types
DPST OFF-MOM (no diode needed for installation) or

Supported LED Types
LED lights with current draw of 20mA or less

Precision and Compatibility with Garmin GNA10

The Garmin GNA10 jog lever adapter is designed to provide pilots and aviation enthusiasts with unparalleled precision and control. Specifically engineered for easy integration with Garmin avionics systems, this adapter enhances the functionality of the existing jog lever control, allowing for smooth and accurate adjustments during flight. Its compatibility ensures a seamless fit, making it a reliable addition to any Garmin setup. Whether in a simulator or actual aircraft, the Garmin GNA10 delivers robust performance and intuitive handling, improving operational efficiency.

Durable Build for Long-Lasting Performance

Built with high-quality materials, the Garmin GNA10 jog lever adapter offers durability that withstands rigorous use in demanding aviation environments. Its sturdy construction protects the internal components from wear and tear, ensuring consistent performance over time. The adapter's lightweight design also avoids adding unnecessary bulk, preserving the ergonomics of your flight control setup. This durability guarantees that operators can rely on the Garmin GNA10 for both casual simulation use and professional flight applications without compromise.

Easy Installation and User-Friendly Design

Installing the Garmin GNA10 jog lever adapter is straightforward, allowing users to upgrade their flight control system quickly without specialized tools. The adapter features a user-friendly design that aligns perfectly with Garmin equipment interfaces, reducing setup time and minimizing troubleshooting needs. Its intuitive layout complements pilot workflows, making fine-tuned control adjustments effortless. This accessibility makes the Garmin GNA10 an excellent choice for both novice users and seasoned pilots looking to enhance their avionics capabilities with minimal hassle.
