ICY DOCK ToughArmor MB873MP-B V2 8-Bay M.2 NVMe SSD PCIe 4.0 Enclosure for 5.25" Drive Bay

Icy Dock ToughArmor MB873MP-B V2 Drive Enclosure for 5.25" M.2, PCI Express NVMe 4.0 - SFF-8612 OCuLink Host Interface Internal - Black

The ICY DOCK ToughArmor MB873MP-B V2 is a robust and versatile 8-bay M.2 NVMe SSD enclosure designed to maximize storage capacity within a standard 5.25" optical drive bay. Crafted from full-metal construction, this enclosure provides durability and effective heat dissipation, making it suitable for high-performance computing environments. It supports up to eight PCIe 4.0 NVMe SSDs of various lengths, including 2230, 2242, 2260, 2280, and 22110, allowing for extensive storage options in compact systems. The enclosure connects via eight OCuLink (SFF-8612) connectors, delivering data transfer speeds up to 64Gbps per drive bay, which is twice the bandwidth of PCIe 3.0 and ten times faster than SATA standards. This high-speed performance is ideal for data centers, workstations, and demanding applications requiring rapid data access and transfer. The enclosure features dual 40x20mm cooling fans at the rear, ensuring optimal thermal management by reducing heat generated during sustained high-speed operations. Additionally, the removable drive trays incorporate a patent-pending adjustable M.2 locker mechanism, enabling tool-less installation and removal in less than 10 seconds. This feature simplifies drive maintenance and replacement, saving time and reducing the risk of damage. Compatibility has been expanded to include Tri-Mode controller cards from leading brands like Broadcom and Areca, providing flexible integration options for advanced host systems. The MB873MP-B V2 also supports power through two 15-pin SATA power connectors, and its rugged full-metal enclosure meets flammability standards, ensuring safety and longevity. For enhanced management, drive ID plugs are included to help keep track of each SSD, and the enclosure utilizes anti-vibration technology to create a stable environment for your drives. The device supports a wide range of M.2 SSD lengths and brands, offering flexibility for various storage needs. Whether upgrading a high-performance PC, building a compact server, or expanding a workstation, this enclosure provides a reliable, high-speed, and easy-to-maintain solution for modern storage demands.

Features:

• Supports 8 x PCIe M.2 NVMe SSDs of all lengths - 30mm (2230), 42mm (2242), 60mm (2260), 80mm (2280), and 110mm (22110)

• Installs into 1 x standard external 5.25" optical drive bay

• Uses 8 x OCuLink (SFF-8612) to connect, pin-out defined by SFF-9402 Rev 1.1

• Supports PCIe 4.0 specifications with transfer rates up to 64Gbps per drive bay

• Powers 8 x M.2 SSDs through 2 x 15-pin SATA power connectors

• Rugged, full-metal enclosure meets flammability requirements

• Equipped with high-performance dual 40 x 20mm cooling fans

• Removable drive tray with tool-less drive installation for easy drive maintenance

• Huge heatsink trays with thermal pads included dispersing heat from the drives

• Anti-Vibration Technology creates a stable environment for SSDs

• Active Power Technology saves power by shutting off the enclosure when no drive is installed

• EMI Grounding protects SSDs from electrical damage

• Drive ID plugs included to keep track of each drive

• Eagle-hook tray latch securely holds the drive tray inside the enclosure
