4-In-1 Flush Vertical Surface Mount - 316L Marine Grade Stainless Steel - Recess Mount Dome
Iris Sx76 series camera is the first of its kind designed to be installed into a bulkhead or vertical surface. Its waterproof stainless steel case is machined from marine-grade 316L stainless steel, which means it will not corrode in harsh saltwater environments, making it a great option as a backup or docking camera for boats. By mounting the camera on the sides of your boat, it can even be used when mooring alongside jetties or pontoons.
During installation, the cameras inner ball can be adjusted and locked into position by tightening the outer bezel to achieve the desired view.
For analog or analog hi-def (such as TVI / CVI / AHD) systems, the S076 version features 1080P resolution. The camera also outputs a CVBS signal for legacy composite video systems.
As well as marine applications, the camera's tough case, and small footprint make it a perfect visibility aid for recreational vehicles, fire and rescue trucks, and other applications requiring a robust and reliable high-definition camera.
The camera is certified to EN60945, EN55032, EN55035, and EN60529 (IP66) and is ONVIF compliant. For marine applications, the camera is directly compatible with Raymarine LH2 and above, Simrad, Lowrance, and B G. For Garmin systems, use them in conjunction with Iris CMAC systems.
Features:
- 1.8mm standard lens (160-degree horizontal field of view)
- Corrosion-Proof 316L Marine Grade Stainless Steel
- Available in 4-in-1 (CVBS, TVI, CVI, AHD) IP formats
- Analogue Hi-Def resolutions up to 1920x1080P resolution
- IP Version - Max 3MP Hi-Def Resolution
- Super wide angle 160-degree lens
- IP version supports PoE and 12VDC - ultra-low power
- Built-in infrared LED illumination (10m range)
- EN60945, EN55032, EN55035, EN50529 (IP66) , FCC, CE
- Shock vibration proof
- Super rugged and easy to install
Applications:
- Perfect for extreme environments
- Workboats tug boats
- Fishing vessels
- Engine room monitoring
- Law enforcement military
- Wind farm vessels
- SUVs, RVs, work vehicles, and trucks
- Luxury vessels
- Passenger ferries cruise liners
Specifications:
- Lens (millimeter): 1.8mm
- Horizontal Field of View: 160-degree HFOV
- Sensor (inch): Sensor 1/4 CMOS Sensor
- Resolution: CVBS: 960H / AHD, HD-TVI. HD-CVI: 1920 x 1080
- Interface: OSD Menu via in-line Joystick in Cable Tail
- Video Processing: Analogue / Analogue HD
- Protocols/Video Format: 1VPP / 75 composite / AHD/TVI/CVI formats
- Onvif: NA
- Bitrate: NA
- Illumination: 6 x 850nm Infra-Red - 10-meter range
- Lens/Field of View: 1.8mm Standard (160-degree HFOV)
- Mirroring: Horizontal vertical configuration via the OSD
- Automatic Gain Control: Supported / multiple levels
- Compatibility: CVBS: All MFDs / Screens featuring composite video input AHD/TVI/CVI via interface or IRIS CMAC System
- Operating Temperature: -30 + 60-degrees C
- Connections: Video: Video - 75 BNC female / 2.1mm DC socket
- Material: Marine Grade 316L Stainless Steel (highly polished as a standard)
- Power: +12VDC (+10 +15VDC range) / 1W Nominal / 1.8W max. (LEDs on)
- Power Over Ethernet (PoE): NA
- Weight Dimensions: 88mm x 22.25mm above and below the mounting surface
- Environmental: EN60529 / IP66
- EMC: EN55032:2015/A11:2020 EN55035:2017/A11:2020 EN60945:2002 Sections 9 10 / FCC Part 15 A B
- RoHS: EN6300:2018
This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns.
The Iris Innovations IRIS-S076 is a versatile 4-in-1 flush-mounted dome camera designed for vertical surface installation, making it ideal for marine, industrial, and recreational applications. Constructed from durable 316L marine-grade stainless steel, this camera offers exceptional corrosion resistance, ensuring reliable operation in harsh saltwater environments such as boats, work vessels, and offshore platforms. Its compact, recessed design allows seamless integration into bulkheads and vertical surfaces, providing unobtrusive surveillance with adjustable ball mounting for precise viewing angles. During installation, the inner ball can be easily adjusted and locked into position by tightening the outer bezel, enabling quick setup and optimal field of view without extensive effort.
Features:
- 1.8mm standard lens with a 160-degree horizontal field of view for comprehensive coverage
- Corrosion-proof 316L marine-grade stainless steel housing suitable for harsh environments
- Supports 4-in-1 video formats: CVBS, TVI, CVI, and AHD, ensuring compatibility with various systems
- High-definition analog video output up to 1920x1080P resolution for clear image quality
- IP66 rated waterproof and dustproof construction certified to EN60529 standards
- Built-in infrared LEDs with a 10-meter illumination range for night vision
- Supports PoE and 12VDC power options, offering flexible installation and low power consumption
- Shock and vibration resistant design for rugged use in demanding conditions
- Easy to install with a compact footprint, suitable for RVs, fire trucks, law enforcement, and marine vessels
- Certified to meet international standards including EN60945, EN55032, EN55035, FCC, and CE
