Jabsco HotShot HD4 24V Heavy Duty Washdown Pump - 4 GPM, 60 PSI

HotShot HD4 Heavy Duty Washdown Pump - 24V - 4 GPM - 60 PSI

Years of clean decks and satisfaction in the form of robust and reliable high-flow and high-pressure diaphragm pumps. The Jabsco legacy of exceptional products continues with this updated and improved lineup of washdown pumps and kits.

HD (Heavy Duty) models include a wider diameter motor with a powder coated shell, cast aluminum endbells and lower housing to improve pressure capability and life.

Standard models provide exceptional performance in an economical footprint. A plastic housing protects the motors from corrosion.

Features:

• Co-molded diaphragm technology for long life and durability
• HD models feature heavy duty, motors and cast aluminum lower housings which allow for long-life, even at high pressures
• Efficient and quiet operation
• Integrated, sealed pressure switch for on-demand operation
• Self-priming allows for installation versatility
• Can run dry without damage
• Quick connect ports for ease of installation, servicing, and maintenance
• Vibration dampening mounting feet
• Full kit versions available which include 25' (7.6m) hose coil

Specifications:

• Motor design: Brushed, permanent magnet TENV
• Pumphead upper housing material: Glass fiber reinforced polypropylene
• Diaphragm: Co-molded TPV
• Check valves: EPDM
• Max inlet pressure: 30 PSI (2.1 Bar)
• Fluid temperature range: 32F 140F (0C 60C)
• Dry self-priming capability: 7ft min (2.1m min)
• Certifications: CE, ISO8846, RCM
• Ingress protection: IPX6

Fittings Accessories:

• Quick Connect straight hosebarb and GHT fittings. Size varies by model.
• 90 20 mesh Quick Connect strainer
• Trigger nozzle Quick Connect hose adapters
• Kit version includes 25' HoseCoil

WARNING: This product can expose you to chemicals including ANTIMONY OXIDE (ANTIMONY TRIOXIDE) which is known to the State of California to cause cancer. For more information go to P65Warnings.ca.gov.

The Jabsco HotShot HD4 Heavy Duty Washdown Pump delivers reliable high-flow performance with a robust design tailored for demanding environments. This 24-volt diaphragm pump offers a flow rate of 4 gallons per minute and a pressure of 60 PSI, making it ideal for deck cleaning, equipment rinsing, and other heavy-duty applications. Its durable construction features a cast aluminum lower housing, powder-coated shell, and a glass fiber reinforced polypropylene pump head, ensuring long-lasting operation even under continuous use. The pump's efficient and quiet operation is complemented by integrated, sealed pressure switches that enable on-demand activation, saving energy and reducing wear.

Designed for versatility, the HD4 model is self-priming up to 7 feet and can run dry without damage, providing flexibility during installation and operation. Quick connect ports facilitate easy installation, maintenance, and servicing, while vibration dampening feet help reduce noise and movement during operation. The pump is equipped with co-molded TPV diaphragms and EPDM check valves for enhanced durability and chemical resistance. It also features a compact footprint suitable for constrained spaces and includes options for full kits with a 25-foot hose coil for immediate deployment.

Safety and compliance are prioritized, with the pump certified CE, ISO8846, and RCM standards, and protected by an ingress rating of IPX6. The Jabsco HotShot HD4 is a reliable choice for marine, industrial, and commercial applications where high performance and durability are essential. Its corrosion-resistant plastic housing protects the motor from environmental elements, ensuring consistent operation over time. Whether used for routine cleaning or demanding washdown tasks, this pump provides the power and reliability needed for professional results.

Features:

• Co-molded diaphragm technology for long life and durability

• Heavy-duty motors and cast aluminum lower housings for enhanced pressure capability and longevity

• Efficient and quiet operation for user comfort

• Integrated, sealed pressure switch for on-demand operation

• Self-priming capability up to 7 feet for installation flexibility

• Can run dry without damage, reducing maintenance concerns

• Quick connect ports for easy installation and servicing

• Vibration dampening mounting feet for reduced noise and movement

• Full kit options include a 25-foot hose coil for immediate setup
