Jabsco Impeller Kit - 6 Blade Nitrile Pump Impeller for Marine and Engine Cooling Systems

Impeller Kit

Material:Nitrile
Drive Type:Single Flat Drive
Number of Blades:6
Dimensions:

• Diameter:2"

• Shaft Width:5/16"

• Shaft Diameter:7/8"

Insert Material:Plastic


Jabsco flexible impellers can be fitted to most makes and models of bronze flexible impeller engine cooling, bilge, transfer and general purpose pumps.
Jabsco flexible impellers are subjected to rigorous quality processes to ensure reliable, efficient and long lasting performance.

Replace all impellers at least once every year, or sooner, depending on the engine duty. When the installation is correct an impeller may last for several years, but it is always advisable to stick to a schedule of preventative, rather than corrective, maintenance.

Replacing impellers is easy. By removing the end cover screws, it is =possible to remove the impeller by using either a Jabsco Impeller Removal Tool, or channel lock pliers, to grip the hub of the impeller. Dont use screwdrivers as they may damage the face of the pump body, causing leaks, and they can be dangerous in confined spaces.

Always carry spare impellers on board in case of emergency. The impeller is one of the most vital components of the engine cooling system and should always be treated as such.

Always grease new impellers. Firstly, it makes it easier to install the impeller into the pump bore, and secondly it gives added protection to the impeller during initial prime. After replacing the gasket and end cover the pump is ready to use.

WARNING: This product can expose you to chemicals including LEAD which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

The Jabsco Impeller Kit (Part Number: 6303-0003-P) features a durable 6-blade nitrile impeller designed for reliable performance in various pump applications. Crafted with a single flat drive and plastic insert, this impeller is suitable for engine cooling, bilge, transfer, and general-purpose pumps. Its 2-inch diameter ensures compatibility with a wide range of systems, providing efficient fluid movement and consistent operation.

Constructed from high-quality nitrile material, the impeller offers excellent chemical resistance and longevity under demanding conditions. The blade design enhances flow efficiency, while the shaft width of 5/16 inch and shaft diameter of 7/8 inch ensure secure fitting within compatible pumps. This kit simplifies maintenance, enabling quick replacement to keep your system running smoothly.

Replacing the impeller is straightforward; simply remove the end cover screws, then use a Jabsco Impeller Removal Tool or channel lock pliers to grip the hub and extract the impeller. Proper greasing during installation facilitates easier fitting and provides added protection during initial priming. Regular replacement—at least annually or more frequently based on engine duty—is recommended to prevent system failures and ensure optimal performance. Always carry spare impellers onboard for emergencies, and adhere to scheduled maintenance practices.

Designed to meet rigorous quality standards, Jabsco flexible impellers are compatible with most makes and models of bronze flexible impeller pumps. They undergo strict testing to ensure durability and efficiency, making them a reliable choice for marine, industrial, and engine cooling applications. Proper installation and maintenance will extend the life of the impeller, with some units lasting several years when cared for correctly.

Note: Always grease new impellers to facilitate installation and protect during initial prime. Be aware that this product may contain chemicals such as lead, which are regulated under California’s Proposition 65. For more information, visit P65Warnings.ca.gov.

Features:

• Material: Nitrile for chemical resistance and durability

• Drive Type: Single flat drive for secure fitting

• Number of Blades: Six blades for efficient fluid transfer

• Diameter: 2 inches suitable for various pump models

• Shaft Width: 5/16 inch for compatibility with pump shafts

• Shaft Diameter: 7/8 inch ensuring proper fit

• Insert Material: Plastic for reliable operation

• Easy Replacement: Designed for straightforward maintenance

• Compatibility: Fits most bronze flexible impeller pumps

• Quality Assurance: Undergoes rigorous testing for performance and longevity
