Lopolight Masthead/360-Degree Navigation Light - 3NM Range with Silver Aluminum Housing and FB Base

Masthead/360-Degree Light - 3NM - Silver Housing with FB Base

This white 360-degree/masthead light has a silver housing, is horizontally mounted, and has a three-nautical-mile range. The FB base centers the wiring for antenna-type pole mountings. The base provides a screw-down onto the deck solution as well as a from-below mounting. Essentially, the base provides a sleeker, reduced profile.

Features:

• Silver anodized aluminum housing
• 0.75m cable is included

Specifications:

• Approved To: COLREG72,EN14744,IEC 60945,IACS E10,USCG,ABS,M.E.D.,DNV,LR
• Mounting: Horizontal
• EAN: 5704438043534
• Min. Feed Wire Gauge: 0.5mm² AWG22
• Light Color: White
• Visibility: 3NM
• Included In the Package: 1 Navigation light, pre-cabled with 0.75 meter shielded marine grade cable and installation guide
• Materials: Silver anodized aluminum 25, PMMA lens, A4 stainless steel screws, Epoxy, Polyurethane
• IP rating: IP68
• Connection: 0.75m cable
• Current Consumption (mA @ 24VDC): 148
• Current Consumption (mA @ 12VDC): 300
• Dimensions Metric: 92.5mm x 36mm
• Dimensions Imperial: 3.6" x 1.4"
• Operating Temperature: -25 degrees C to 55 degrees C
• Operating Voltage: 10-32VDC
• Power Draw (W): 3.6
• Vessel Size: Under 12-20 meters

The Lopolight Masthead/360-Degree Light (Part Number: 201-021-FB) is designed for vessels under 20 meters, providing reliable navigation visibility with a 3-nautical-mile range. Featuring a durable silver anodized aluminum housing, this horizontally mounted light ensures optimal performance in harsh marine environments. The integrated FB base allows for a sleek, low-profile installation with options for deck screw-down or from-below mounting, offering flexibility and a clean aesthetic. The pre-cabled design includes a 0.75-meter shielded marine-grade cable, simplifying installation and minimizing setup time. Constructed with high-quality materials such as PMMA lens, A4 stainless steel screws, epoxy, and polyurethane, the light meets strict maritime safety standards including COLREG72, IEC 60945, USCG, ABS, and DNV certifications. The IP68-rated enclosure guarantees water and dust resistance, ensuring durability even in challenging marine conditions. Operating within a voltage range of 10-32VDC, the light consumes approximately 3.6 watts, with current draw varying from 148mA at 24VDC to 300mA at 12VDC, making it energy-efficient and suitable for various power sources. Its compact dimensions make it ideal for vessels with limited space, and its temperature tolerance from -25°C to 55°C allows reliable operation across diverse climates. The Lopolight Masthead/360-Degree Light combines robust construction, versatile mounting options, and compliance with international standards, making it an excellent choice for enhancing vessel safety and visibility at night or in low-light conditions.

Features:

• Silver anodized aluminum housing for durability and corrosion resistance

• Pre-cabled with 0.75m shielded marine-grade cable for easy installation

• Horizontal mounting design for versatile vessel placement

• FB base provides a sleek, low-profile installation with deck screw-down or from-below options

• 3 nautical miles visibility for effective navigation signaling

• Complies with COLREG72, IEC 60945, USCG, ABS, DNV and other maritime safety standards

• IP68 rated enclosure ensures protection against water and dust ingress

• Operating voltage range of 10-32VDC for flexible power supply compatibility

• Energy-efficient with a power draw of approximately 3.6 watts

• Compact size suitable for vessels under 20 meters in length

• Designed for reliable operation in temperatures from -25°C to 55°C
