Newmar Power 12-12-6i Power Stabilizer for Sensitive Electronics

12-12-6i Power Stabilizer

Feed sensitive electronics with proper voltage, regardless of the battery condition. This stabilizing converter provides continuous, precisely regulated output over the entire range of a batterys usable voltage. This prevents subjecting loads to fluctuating input voltage, which can cause shutdown, diminish performance, and possibly damage sensitive circuitry.

This converter provides total input/output isolation, virtually eliminating conducted line noise and permitting the connection of negative ground gear to positive or floating ground systems, or vice versa. It can be modified for use as a battery charger, allowing them to maintain a battery at a great distance from the primary voltage source, providing reserve power if the main source fails. The rugged anodized aluminum case is ideal for marine applications.

Application Benefits Include:

• Operate electronics at optimal input voltage, even from nearly drained batteries
• Boost voltage to compensate for voltage drops in long wire runs from batteries
• Eliminate voltage drops during momentary high current drain from batteries, as during engine start
• Eliminate voltage fluctuation from charge sources
• Eliminate voltage overshoot due to sudden removal of high current load

Specifications:

• Input Voltage: 10-16
• Input Amps: 8
• Output Voltage: 13.6
• Output Amps (Intermittent): 6
• Output Amps (Continuous): 6
• Case Size (H x W x D): 6.5 x 4.0 x 1.75 inches (6.8 x 10.2 x 4.5 centimeters)
• Weight: 2 lb. (.9 kg)
• Output: 12 or 24V, nominal, see matrix
• Ripple: 150 mV P-P maximum
• Regulation: 1% Line/Load

Duty Cycle Ratings:

• Intermittent: 20 minutes max on time, 20% duty. The current limit is set at approx. 105% of intermittent rating.
• Continuous: 24 hours, 100% duty
• Idle Current: Less than 100 mA (including power ON light )
• Operating Temp: 0-50 degrees C, Derate Linearly From 100% @ 40 degrees C To 50% @ 50 degrees C. Thermal shutdown @ 70 degrees C Case Temperature.
• Switching Frequency: 40 kHz.
• Efficiency: 85% Typical.
• Isolation Output/Chassis; Input/chassis: 250 VDC

Mechanical Specifications:

• Anodized aluminum heat sink case
• Front panel terminal block
• Heavy-duty mounting flange
• Conformal-coated PC board

Options/Factory Modifications:

• Operation as a battery charger (contact factory)
• Parallel/redundant operation (contact factory)
• High-vibration mounting kit
• Non-standard output voltage (contact factory)

Option: Extreme Vibration Mounting Kit

The Extreme Vibration Mounting Kit is available to protect NEWMAR power converters from the extreme stresses of shock and vibration when mounted on high-vibration vehicles.

The kit (pictured here) replaces the standard vibration kit provided with the unit and fits into the units mounting flange to act as a super shock absorber for electronics in high-vibration applications. It is available to fit all NEWMAR units from 2 to 70 lbs. Specify KITL for units that weigh 215 lbs. and KitH for units that weigh 16-70 lbs.

The Newmar Power 12-12-6i Power Stabilizer is designed to provide precise voltage regulation for sensitive electronic devices in a variety of environments. Its unique design ensures that your equipment receives a stable 13.6V output, regardless of fluctuating input voltages from nearly drained batteries or long wire runs. This functionality helps prevent shutdowns, performance drops, and potential damage caused by voltage spikes or dips. The stabilizer's total input/output isolation minimizes line noise, making it suitable for connecting negative ground gear to positive or floating ground systems without interference. Its rugged anodized aluminum case is ideal for marine or harsh environments, offering durability and reliable performance under demanding conditions.

Features:

• Input Voltage: 10-16V DC range for versatile power sources

• Output Voltage: 13.6V with 1% regulation for consistent performance

• Output Current: 6 Amps continuous, 8 Amps peak for various loads

• Total Isolation: Eliminates conducted line noise and allows flexible grounding options

• Thermal Management: Thermal shutdown at 70°C for safety and longevity

• Efficiency: Typical 85% for energy conservation

• Switching Frequency: Operates at 40 kHz for smooth regulation

• Durable Construction: Anodized aluminum case with heavy-duty mounting flange

• Versatile Use: Can be modified as a battery charger or used in parallel/redundant configurations

• Vibration Resistance: Optional extreme vibration mounting kit available for high-vibration applications
