Newmar Power ES-7D Elite DC Panel for Expanding AC/DC Circuit Capacity

ES-7D Elite DC Panel

This panel is designed for expanding AC or DC circuit capacity on any Elite Series panel, or it may be used as a stand-alone load center.

Features:

• AC (120/240V) or DC (12/24V) master breaker (double pole AC 50 amp* standard, 30 amp optional, or DC 100 single pole amp standard; 50 or 75 amp optional
• 16 branch circuit capacity, 12 installed standards: ES-7A: 2-10A, 5-15A, 5-20A ES-7D: 2-5A, 3-10A, 5-15A, 2-20A

Specifications:

• Size (W x H x D): 5.25 x 15 x 4 inches
• Weight: 7 lbs. (3.2 kg)

Note: 50-amp master is OK for use on 230 VAC line-to-line systems. For 230 VAC line-to-neutral systems, 30 amp is the maximum master breaker value.

The Newmar Power ES-7D Elite DC Panel offers a versatile solution for expanding your electrical system's capacity, whether you're working with AC or DC circuits. Designed for use with the Elite Series panels or as a standalone load center, this panel simplifies integrating additional circuits with reliable performance. Its compact size makes it suitable for a variety of applications, providing efficient power distribution without taking up excessive space. The panel features a master breaker capable of handling 120/240V AC or 12/24V DC systems, with standard and optional amperage ratings to match your specific needs. The 50-amp double pole breaker is suitable for 230 VAC line-to-line systems, while a 30-amp breaker is recommended for 230 VAC line-to-neutral configurations. With 16 branch circuit capacity and 12 pre-installed circuits, the ES-7D supports a range of circuit configurations, including 2-10A, 5-15A, and 5-20A options, depending on the model. Its sturdy construction and straightforward installation make it an ideal choice for both residential and commercial electrical systems. The panel's dimensions are designed for easy integration into existing setups, and its weight of approximately 7 pounds ensures durability without sacrificing portability. Whether expanding an existing system or starting anew, the Newmar Power ES-7D Elite DC Panel provides the flexibility and reliability necessary for safe and efficient power management.

Features:

• AC (120/240V) or DC (12/24V) master breaker with standard 50 amp double pole AC or 100 amp single pole DC options

• Supports up to 16 branch circuits with 12 pre-installed circuits for versatile wiring configurations

• Compact dimensions for easy installation in tight spaces

• Designed for use with Elite Series panels or as a stand-alone load center

• Suitable for 230 VAC line-to-line systems with a 50-amp breaker, or 230 VAC line-to-neutral systems with a 30-amp breaker
