Newmar Power GI-30-FS Galvanic Isolator 30A Fail Safe for Marine Protection

GI-30-FS Galvanic Isolator 30A Fail Safe

Installing the Galvanic Isolator between the AC safety ground and DC bonding system blocks most of the low-voltage currents and corrosive action seen on the vital metallic components in the saltwater. With the low voltage current blocked, the galvanic corrosion effect on the sacrificial anodes is significantly reduced, while the integrity of the critical safety ground path is maintained. This means a significant saving in boat haul-out fees and zinc replacement costs. For additional safety, all units feature a large capacitor, providing a secondary low-impedance path for sending AC current to the ground.

Newmars latest galvanic isolator meets the latest ABYC A-28 2019 requirements, including being a failsafe. This design can meet the strictest temperature and current tests to create a robust solution for galvanic protection.

Features:

• Protects against corrosion
• Maintains a safe environment
• Certified to the UL1500 standard for Ignition Protection
• Tested to a 50 degrees C ambient temperature
• The 30A fail-safe feature ensures ground maintenance
• Connection in the event of isolator failure

Specifications:

• Shore Power Voltage: 115230V
• Maximum Short Circuit: 5000 Amps
• Stray Current Protection: Up to 1.4 VDC
• Dimensions (LxWxH): 200 x 189 x 68.5 mm

The Newmar Power GI-30-FS Galvanic Isolator provides essential galvanic protection for saltwater vessels by effectively blocking low-voltage currents that cause corrosion on vital metallic components. Installing this isolator between the AC safety ground and the DC bonding system significantly reduces galvanic corrosion and extends the lifespan of sacrificial anodes, resulting in lower zinc replacement costs and fewer haul-out fees. Its fail-safe design ensures continuous ground maintenance even in the event of isolator failure, enhancing overall safety and reliability on your boat. Built with a large capacitor, the GI-30-FS creates a secondary low-impedance path for AC current, further safeguarding your vessel’s electrical integrity. The unit complies with the latest ABYC A-28 2019 standards, demonstrating its robust construction and adherence to safety regulations. It is tested to operate reliably at ambient temperatures up to 50°C and is certified under UL1500 for ignition protection, making it suitable for demanding marine environments. The galvanic isolator supports shore power voltages of 115V to 230V, with a maximum short circuit capacity of 5000 amps and stray current protection up to 1.4 volts DC. Compact yet durable, its dimensions make it easy to install in tight spaces, offering peace of mind for boaters seeking dependable galvanic corrosion prevention. The GI-30-FS is a critical component for maintaining a safe and corrosion-free marine environment, reducing maintenance costs, and ensuring compliance with industry standards. Please note that this product may not be returned to the original point of purchase; contact the manufacturer directly for any issues or concerns.

Features:

• Protects against galvanic corrosion to extend the lifespan of sacrificial anodes

• Maintains a safe electrical environment on marine vessels

• Certified to UL1500 standard for ignition protection ensuring safety

• Designed to withstand ambient temperatures up to 50°C for reliable operation

• Fail-safe 30A feature ensures continuous ground connection in case of isolator failure

• Provides a secondary low-impedance path for AC current to enhance safety
