Newmar Power PT-25W Battery Charger – Marine 12-Volt Smart Charging System

PT-25W Battery Charger

Newmars Phase Three Series Battery Chargers employ Smart battery charging technology for 12-volt systems aboard marine applications including workboats, military vessels, commercial vessels, and recreational craft. This charger interacts with batteries, providing the optimum three-stage charge process for fast recovery and conditioning, maximizing performance, and extending battery life.

A selector switch adjusts output voltage to adapt to gel-cell, flooded lead-acid, or AGM battery types. An optional temperature compensation sensor also adjusts output for ideal voltage based on changes in the batteries ambient temperature. This model is housed in a rugged stainless steel case with a durable white powder coat finish, and the internal circuitry is polyurethane coated for maximum corrosion resistance.

Features:

• 12-volt model
• Smart circuitry provides three-stage charging bulk, absorption, and float
• Gel-Cell/Flooded Lead-acid/AGM battery type switch selects optimum charge/float voltages
• Multiple isolated output banks; ammeter indicates total output current. (Except PT-7)
• The optional sensor adjusts the output voltage based on battery temperature. (Except PT-7)
• Current limitations prevent damage from overloading
• Clean well-regulated output can be used as a power supply; can power loads directly without a battery in line
• Built to last rugged stainless steel case with a durable white powder coat finish, an optional drip shield, and marinized internal circuitry
• Protection: Current Limiting, Thermal Protection, Forced Air Cooling, Drip Shield
• ABS-type approval for battery charging and power supplies

Specifications:

• Input VAC (50-60 Hz.): 90-132 or 180-264
• Input Amps @ Full Load: @ 115 VAC: 6.5, @ 230 VAC: 4
• Power Factor: .7
• Max Output Amps: 25
• Output Banks: 3
• Battery Capacity (Amp-Hours): 50-250
• Operating Temp. Rating Reference: T-4
• Case Size Reference: A-2
• Case Size (H x W x D): 11.2A x 7.7 x 4.75A inches (31.8A x 19.6 x 12.1A centimeters) *Note with Dripshield installed A add 1.1 (2.8 cm) to height and .92 (2.3 cm) to depth
• Weight Lbs./Kg: 8.2/4
• Optional Temp. Sensor Model: TCS-12/24
• Remote Panel Model: RP
• Equalize Option: Yes
• Output Indicator Reference: M-3
• Compliance Reference: CG

Temperature Rating References:

• Temperature: -20 degrees C to +60 degrees C
• Derate Linearly From 100% @ 50 degrees C to 60% @ 60 degrees C

Nominal Output Voltages at Gel/Flooded Switch Settings (without Temperature Compensation):

• Gel-Cell: 14.0 VDC Charge @ 50% load and 13.6 VDC Float @ .5 amp load
• Flooded/AGM: 14.2 VDC Charge @ 50% load and 13.4 VDC Float @ .5 amp load

Compliance References:

• CG: USCG CFR 183.410 (Ignition protected)
• CE: Carries the CE mark
• ABS: PT Series meets SVR 2009 4-8-3/5.9, Under 90 meters Rules 2006 4-6-4/7.19, and HSNC 2007 4-8-3/5.13.

Options:

• Remote Panel, model RP, for use with all models except PT-7 and PT-40U (LEDs indicate charger output stage. Manual re-initialization of three-stage charge cycle. With 25 of cable. Panel dimensions: 3 H x 4.75 W)
• Temperature Compensation Sensor, Model TCS 12/24, for use with all models except PT 7 (-5 mV per cell degrees C, 25 cable (40cable optional)

The Newmar Power PT-25W Battery Charger is engineered for reliable 12-volt battery management in marine environments, including workboats, military vessels, commercial ships, and recreational craft. Featuring advanced Smart circuitry, this charger employs a three-stage charging process—bulk, absorption, and float—to ensure fast recovery, optimal conditioning, and extended battery lifespan. Its intelligent design automatically adjusts the charging profile based on battery type, with a selector switch allowing seamless switching between gel-cell, flooded lead-acid, and AGM batteries for maximum versatility. An optional temperature compensation sensor further fine-tunes voltage regulation based on ambient temperature, ensuring batteries are neither overcharged nor undercharged in varying conditions. The rugged stainless steel case with a durable white powder coat finish, coupled with polyurethane-coated internal circuitry, provides excellent corrosion resistance suitable for harsh marine environments. This model also offers multiple isolated output banks with an ammeter to monitor total current output, ensuring efficient power management throughout your vessel. The PT-25W is equipped with safety features like current limiting, thermal protection, forced air cooling, and a drip shield, making it a dependable choice for demanding applications. Certified by ABS, CE, and compliant with US Coast Guard standards, this charger is built to meet rigorous marine safety and performance requirements. It can serve as a power supply, providing a clean, well-regulated output that can power loads directly without a battery in line, making it versatile for various onboard electrical needs. With a maximum output of 25 amps across three banks and compatibility with batteries ranging from 50 to 250 amp-hours, the PT-25W seamlessly integrates into your vessel’s electrical system, ensuring longevity and optimal performance of your batteries and electrical loads. Optional accessories like a remote panel and temperature sensor provide additional convenience, allowing for easy monitoring and temperature-based voltage adjustments. Designed for durability and efficiency, the Newmar Power PT-25W Battery Charger is a professional-grade solution for maintaining marine batteries and powering electrical systems reliably in demanding marine environments.

Features:

• Smart circuitry provides three-stage charging: bulk, absorption, and float

• Selector switch for gel-cell, flooded lead-acid, or AGM battery types to optimize charging voltages

• Multiple isolated output banks with ammeter for monitoring total output current

• Optional temperature compensation sensor adjusts voltage based on ambient temperature

• Current limiting and thermal protection prevent overload and overheating

• Can be used as a power supply to directly power loads without a battery

• Constructed in a rugged stainless steel case with durable white powder coat finish for corrosion resistance

• Certified by ABS, CE, and compliant with US Coast Guard standards

• Includes optional remote panel and temperature sensor for enhanced monitoring and control

• Designed for marine environments with internal circuitry polyurethane coating and marinized features
