Newmar Power PT-40U Marine Battery Charger with Smart Three-Stage Technology

PT-40U Battery Charger

Newmars Phase Three Series Battery Chargers employ Smart battery charging technology for 12-volt systems aboard marine applications including workboats, military vessels, commercial vessels, and recreational craft. This charger interacts with batteries, providing the optimum three-stage charge process for fast recovery and conditioning, maximizing performance, and extending battery life.

A selector switch adjusts output voltage to adapt to gel-cell, flooded lead-acid, or AGM battery types. An optional temperature compensation sensor also adjusts output for ideal voltage based on changes in the batteries ambient temperature. This model is housed in a rugged stainless steel case with a durable white powder coat finish, and the internal circuitry is polyurethane coated for maximum corrosion resistance.

Features:

• 12-volt model
• Smart circuitry provides three-stage charging bulk, absorption, and float
• Gel-Cell/Flooded Lead-acid/AGM battery type switch selects optimum charge/float voltages
• Multiple isolated output banks; ammeter indicates total output current. (Except PT-7)
• The optional sensor adjusts the output voltage based on battery temperature. (Except PT-7)
• Current limitations prevent damage from overloading
• Clean well-regulated output can be used as a power supply; can power loads directly without a battery in line
• Built to last rugged stainless steel case with a durable white powder coat finish, an optional drip shield, and marinized internal circuitry
• Protection: Current Limiting, Thermal Protection, Forced Air Cooling, Drip Shield
• ABS-type approval for battery charging and power supplies

Specifications:

• Input VAC (50-60 Hz.): 90-264
• Input Amps @ Full Load: @ 115 VAC: 6.8, @ 230 VAC: 3.4
• Power Factor: .98 @ 115V and .95 @ 230V
• Max Output Amps: 40
• Output Banks: 3
• Battery Capacity (Amp-Hours): 80-400
• Operating Temp. Rating Reference: T-5
• Case Size Reference: A-3
• Case Size (H x W x D): 13.85B x 9.5 x 4.8B inches (35.2B x 24.1 x 12.2B centimeters) *Note with Dripshield installed B add .75 (1.9 cm) to height and 1.35 (3.4 cm) to depth
• Weight Lbs./Kg: 11/6
• Optional Temp. Sensor Model: TCS-12/24
• Remote Panel Model: EVM-12-2
• Equalize Option: No
• Output Indicator Reference: M-3
• Compliance Reference: CG

Temperature Rating References:

• Temperature: -20 degrees C to +70 degrees C
• Derate Linearly From 100% @ 50 degrees C to 50% @ 70 degrees C

Nominal Output Voltages at Gel/Flooded Switch Settings (without Temperature Compensation):

• Gel-Cell: 14.0 VDC Charge @ 50% load and 13.6 VDC Float @ .5 amp load
• Flooded/AGM: 14.2 VDC Charge @ 50% load and 13.4 VDC Float @ .5 amp load

Compliance References:

• CG: USCG CFR 183.410 (Ignition protected)
• CE: Carries the CE mark
• ABS: PT Series meets SVR 2009 4-8-3/5.9, Under 90 meters Rules 2006 4-6-4/7.19, and HSNC 2007 4-8-3/5.13.

Options:

• Remote Panel, model EVM-12-2, for us with model PT-40 only (Enables monitoring of when the battery charger is on and the batteries state of readiness, at a glance of two (2) battery banks only)
• Temperature Compensation Sensor, Model TCS 12/24, for use with all models except PT 7 (-5 mV per cell degrees C, 25 cable (40cable optional)

The Newmar Power PT-40U Battery Charger is designed for demanding marine applications, including workboats, military vessels, and recreational craft. Featuring advanced Smart battery charging technology, this 12-volt model delivers optimal three-stage charging—bulk, absorption, and float—to ensure fast recovery, reliable conditioning, and extended battery lifespan. Its intelligent circuitry adapts to gel-cell, flooded lead-acid, or AGM batteries, with a selector switch for easy voltage adjustments. An optional temperature compensation sensor fine-tunes charging based on ambient temperature, maximizing battery performance in varying conditions.

Constructed in a rugged stainless steel case with a durable white powder coat finish, the PT-40U is built for harsh marine environments. Internal circuitry is polyurethane coated for maximum corrosion resistance, and protection features such as current limiting, thermal protection, forced air cooling, and a drip shield enhance durability and safety. The charger provides multiple isolated output banks and an ammeter to monitor total output current, while the ability to operate as a power supply allows loads to be powered directly without a battery. Its compliance with ABS, CE, and US Coast Guard standards confirms its suitability for marine use.

The PT-40U offers versatile features to meet various operational needs. It supports battery capacities from 80 to 400 amp-hours and can provide up to 40 amps of charging current. The unit’s wide input voltage range (90-264 VAC at 50-60 Hz) and high power factor ensure efficient operation across different power sources. Optional accessories include a remote monitoring panel for convenient status checks and a temperature sensor for precise voltage regulation. Overall, the Newmar Power PT-40U Battery Charger combines robust construction, intelligent charging, and versatile features to deliver reliable, long-lasting performance in demanding marine environments.

Features:

• Smart three-stage charging: bulk, absorption, and float for optimal battery health

• Selector switch for gel-cell, flooded lead-acid, and AGM battery types

• Optional temperature compensation sensor for temperature-adjusted charging

• Multiple isolated output banks with ammeter for monitoring output current

• Rugged stainless steel case with durable powder coat finish and corrosion-resistant circuitry

• Protection features include current limiting, thermal protection, and drip shield

• Can operate as a power supply to directly power loads without a battery

• Supports battery capacities from 80 to 400 amp-hours

• Wide input voltage range with high power factor for efficient operation

• Certified for marine use with ABS, CE, and US Coast Guard approvals
