Pacer DT Deutsch Plug Repair Kit TDT06F-4RS for 14-18 AWG Wires, 4-Position

DT Deutsch Plug Repair Kit - 14-18 AWG (4 Position)

Pacer's DT repair kits use the larger size 16 contacts (Deutsch Pin P/N 0460-215-16141, Socket P/N 0462-209-16141) for applications using 14 AWG wires. However, DT series connectors are designed for 20-14 wire gauge applications. The DT series offers electrical designers the ability to use multiple sizes of 16 contacts (20-14 AWG) each with a 13-amp continuous capacity, within a single shell. Pacer also sells these other components for use in a wider range of applications.

Features:

• Packs include all parts needed to assemble a connector
• One to two extra terminals
• Cavity plugs to seal open circuits

Applications:

• Wire-to-wire applications
• Enclosed connectors offer field-proven reliability and rugged quality

Compliances:

• Ingress Protection (IP) Level: IP68 and IP6K9K
• EU RoHS/ELV
• Standard UL-94 Recognized

Characteristics:

• Wedge locks ensure contact alignment and retention
• Redundant Silicone Seals
• Hand-insertable and removable contacts

Technical Specifications:

• Number of Cavities: 4
• Housing: Rectangular receptacle, plastic reinforced with glass fiber
• Contact Size: 16 (13 amp)
• Wire Size: 14 AWG
• Holds Pin/Socket: Sockets
• Operating Temperature: -55C to 125C

Contents:

• (1) 4 pos. plug
• (1) 4 pos. wedge lock
• (5) sockets
• (2) cavity plugs

The Pacer DT Deutsch Plug Repair Kit TDT06F-4RS is designed for reliable wire-to-wire electrical connections in demanding environments. Featuring a 4-position rectangular receptacle housing made of reinforced plastic with glass fiber, this kit is suitable for applications requiring 14 to 18 AWG wire gauge. The kit includes all necessary parts for easy assembly, such as a 4-position plug, wedge lock, five sockets, and cavity plugs to seal open circuits, ensuring a secure and sealed connection. The connectors incorporate wedge locks that guarantee proper contact alignment and retention, while redundant silicone seals provide enhanced ingress protection, meeting IP68 and IP6K9K standards for rugged durability. These features make the kit ideal for use in environments exposed to dust, water, or harsh conditions, providing field-proven reliability and rugged quality for critical applications. Operating across a temperature range from -55°C to 125°C, the kit supports a variety of industrial and automotive uses, offering dependable performance in extreme conditions. The contacts are hand-insertable and removable, simplifying maintenance and repair tasks without compromising connection integrity. Compliant with EU RoHS/ELV standards and recognized under UL-94 flame rating, the Pacer TDT06F-4RS ensures safety and environmental compliance across multiple industries. This comprehensive repair kit is perfect for technicians and engineers seeking a durable, easy-to-assemble solution for complex wiring needs, with the flexibility of multiple contact sizes within a single shell for versatile applications.

Features:

• Includes all parts needed for connector assembly

• Provides one to two extra terminals for future use

• Cavity plugs seal open circuits for environmental protection

• Wedge locks ensure contact alignment and retention

• Redundant silicone seals enhance ingress protection

• Hand-insertable and removable contacts for easy maintenance

• Robust rectangular housing reinforced with glass fiber

• Operates reliably across a broad temperature range from -55°C to 125°C

• Designed for wire gauge sizes from 14 to 18 AWG

• Meets IP68 and IP6K9K standards for rugged environments
