DT Deutsch Receptacle Repair Kit - 14-18 AWG (6 Position)

Pacer's DT repair kits use the larger size 16 contacts (Deutsch Pin P/N 0460-215-16141, Socket P/N 0462-209-16141) for applications using 14 AWG wires. However, DT series connectors are designed for 18-14 wire gauge applications. The DT series offers electrical designers the ability to use multiple sizes of 16 contacts (18-14 AWG) each with a 13-amp continuous capacity, within a single shell. Pacer also sells these other components for use in a wider range of applications.

Features:

• Packs include all parts needed to assemble a connector
• One to two extra terminals
• Cavity plugs to seal open circuits

Applications:

• Wire-to-wire applications
• Enclosed connectors offer field-proven reliability and rugged quality

Compliances:

• Ingress Protection (IP) Level: IP68 and IP6K9K
• EU RoHS/ELV
• Standard UL-94 Recognized

Characteristics:

• Wedge locks ensure contact alignment and retention
• Redundant Silicone Seals
• Hand-insertable and removable contacts

Technical Specifications:

• Number of Cavities: 6
• Housing: Rectangular receptacle, plastic reinforced with glass fiber
• Contact Size: 16 (13 amp)
• Wire Size: 14 AWG
• Holds Pin/Socket: Pins
• Operating Temperature: -55C to 125C

Contents:

• (1) 6 pos. receptacle
• (1) 6 pos. wedge lock
• (8) pins
• (3) cavity plugs

The Pacer DT Deutsch Receptacle Repair Kit (Part Number TDT04F-6RP) is designed for reliable wire-to-wire connections in demanding environments. This kit is suitable for applications requiring 14 AWG wire, utilizing larger 16 contacts that support a continuous 13-amp capacity. The kit features a rugged plastic housing reinforced with glass fiber, ensuring durability and resistance to harsh conditions. Its design incorporates wedge locks to guarantee proper contact alignment and retention, along with redundant silicone seals for enhanced ingress protection. This makes the kit ideal for applications demanding sealed, field-reliable connections in both industrial and automotive settings. The kit includes a 6-position rectangular receptacle, wedge lock, eight pins, and cavity plugs, providing all necessary components for easy assembly and repair. The contacts are hand-insertable and removable, facilitating quick maintenance and modifications without specialized tools. The components conform to multiple safety and quality standards, including IP68 and IP6K9K ingress protection ratings, UL-94 recognition, and compliance with EU RoHS/ELV directives. Operating across a temperature range from -55°C to 125°C, this receptacle kit is versatile for various environments. It is well-suited for applications requiring rugged, sealed connections such as in industrial machinery, off-road vehicles, and other demanding electrical systems. The kit's comprehensive design ensures a secure, long-lasting connection with minimal maintenance, making it a reliable choice for professional electrical assemblies.

Features:

• Includes all parts needed for connector assembly

• Contains one to two extra terminals for flexibility

• Cavity plugs seal open circuits for protection

• Wedge locks ensure contact alignment and retention

• Redundant silicone seals provide ingress protection

• Hand-insertable and removable contacts for easy maintenance

• Durable plastic housing reinforced with glass fiber

• Supports wire sizes from 14 to 18 AWG with 16 contacts
