SKU:104997
Tinned Lug 1/0 AWG - 3/8 Stud Size - 10 Pack
Creating a strong connection is essential to every electrical system. By using closed-end lugs, users get not only durability but longevity as well. Pacers closed-end lugs are tin-plated and have no exposed seams. This means that they are ideal for marine applications. What makes them ideal is the fact that they can be used to create waterproof connections. When used with epoxy heat shrink, the closed end lug will fully envelop the conductor. This leaves nothing exposed to the elements. To use, simply strip your wire or cable to the proper length. Once this is complete, slide the lug over the exposed wire, making sure the insulation butts up to the edge of the lug.
Now, crimp the lug using the correct tool, and youre done. Add epoxy lined heat shrink for added durability. Pacers closed-end lugs are available in 8 AWG to 4/0 AWG wire sizes. The available stud sizes include #10, 1/4, 5/16, 3/8, and 1/2. Selecting the correct closed-end lug isnt an easy task. Contact a Pacer expert today with any questions that you may have.
Features:
Compliances:
Specifications:
The Pacer Tinned Lug Part Number TAE1/0-38R-10 is designed to ensure reliable and durable electrical connections, particularly suited for marine and harsh environment applications. Crafted from seamless tubes of 99.9% copper, these lugs provide high conductivity and long-lasting performance. The tin-plated finish enhances corrosion resistance, making them ideal for environments exposed to moisture and saltwater. Each lug features no exposed seams, which contributes to their waterproof properties, especially when combined with epoxy heat shrink tubing for a fully sealed connection. These lugs are rated for 600 volts and are suitable for stranded copper wires, providing versatility across various electrical systems.
Installation is straightforward: strip the wire to the proper length, slide the lug over the exposed conductor ensuring the insulation butts up to the lug's edge, then crimp or solder using the appropriate tool. The lug’s highly controlled flare facilitates easy cable insertion, and the tight barrel-to-pad transition offers an extended usable length for secure connections. The larger contact pad area ensures optimal contact and electrical performance, while the stud size options, including 3/8 inch, cater to different mounting requirements. Marked on the lug are the cable size and stud hole for easy identification, streamlining installation processes. These features make the Pacer closed-end lugs a reliable choice for demanding electrical applications.
Compliance with industry standards such as ASTM-B-152, RoHS, and UL/CSA approvals ensures that these lugs meet rigorous safety and quality requirements. The product’s packaging includes ten lugs per pack, providing sufficient quantity for multiple connections in marine, industrial, or automotive electrical systems. Whether used for crimping or soldering, these lugs deliver dependable, waterproof, and corrosion-resistant connections that ensure the longevity and safety of your electrical system.
Features:
