Panorama Antennas L[G]M[X]M[X]-6-60[-24-58] 5G Multi-Function Panel Antenna with GPS/GNSS Support

Panorama Antennas L[G]M[X]M[X]-6-60[-24-58] Antenna

The Panorama Antennas L[G]M[X]M[X]-6-60[-24-58] is a versatile, high-performance panel antenna designed to deliver up to 22 4G/5G MIMO streams across the 617-960 MHz and 1427-6000 MHz frequency ranges. Its robust, low-profile form factor makes it suitable for various in-vehicle and fixed applications, offering a ground plane independent solution that can be mounted on both conductive and non-conductive panels. Equipped with integrated flame-retardant RG174 cables and a halogen-free radome, this antenna is engineered for durability and safety in demanding environments, including those requiring ingress protection up to IP69K and vandal resistance meeting IK10 standards.

Features:

• The 'Great White' 5G version: Optimized for next-generation mobile connectivity with enhanced performance.

• Upto 9 functions inside a low profile housing: Combines multiple functionalities including LTE, 4G/5G MIMO, and GPS/GNSS into a compact design.

• Ground plane independent antenna solution: Suitable for diverse installation environments without the need for a traditional ground plane.
