Pro-Guide Batteries PGC-110 12V 10-Amp On-Board Battery Charger for Lead-Acid, AGM, and Lithium Batteries

1 Bank On-Board Battery Charger - 12V - 10-Amp

The Pro-Guide GPC-110 is a 12V on-board battery charger for lead-acid, AGM, and lithium batteries.

Select one of three charge profiles.

Activation Mode supplies a short supply of voltage to wake any asleep Lithium Battery, or hold the button for (3-5) seconds to enter a manual Activation Mode.

The PGC Line is designed to stay plugged in year-round. With the Intelligent PGC Algorithm, each PGC Charger checks each batterys state of charge on a specific timeline, ensuring that youll be fully charged for your next adventure.

With over 40 years of experience, Pro-Guide is proud to stand behind this charger with a 2 Year Free and 4 Year Total Warranty.

Protection:

• Output Over-Voltage
• Output Over Current
• Output Short Circuit
• Output Reverse Polarity
• Over Temperature

Input:

• Input Voltage: AC 110-120V
• Frequency: 60Hz
• Input Current: <6A

Specifications:

• Battery Type: Lead Acid/AGM/Lithium
• Output Voltage: DC 12V x 1
• Max Output Voltage: 14.1-14.3 for Lead Acid Battery, 14.3-14.7 for AGM Battery, 14.4-14.7 for Lithium Battery
• Output Current: 10A x 1
• Length: 6.02
• Width: 9.96
• Height: 3.86
• Weight: 9.5 lbs
• IP Rating: 68

The Pro-Guide PGC-110 is a versatile 12V on-board battery charger designed to keep your lead-acid, AGM, and lithium batteries fully charged and ready for use. Its intelligent charging algorithm automatically checks each battery's state of charge on a specific timeline, ensuring optimal performance and longevity. The charger features three selectable charge profiles, allowing you to customize the charging process based on your battery type and needs. An activation mode supplies a brief voltage pulse to wake any sleeping lithium batteries, while a manual activation option enables you to hold the button for 3-5 seconds for additional control. This design allows the charger to stay plugged in year-round, making maintenance effortless and hassle-free.
Built with advanced protection features, the PGC-110 safeguards your batteries and electrical system. It includes over-voltage, over-current, short circuit, reverse polarity, and over-temperature protection, ensuring safe operation under various conditions. The charger is powered by a standard AC 110-120V supply, drawing less than 6 amps at 60Hz, making it suitable for most applications. Its compact size and durable IP68 rating provide reliable performance in demanding environments, whether installed in vehicles or marine vessels. With over 40 years of industry experience, Pro-Guide Batteries backs this charger with a 2-year free warranty and a total of 4 years of coverage, reflecting its quality and durability.
The PGC-110 features a maximum output voltage of 14.1-14.3 volts for lead-acid batteries, 14.3-14.7 volts for AGM batteries, and 14.4-14.7 volts for lithium batteries, with a maximum output current of 10 amps. Its small footprint and lightweight design make installation straightforward, while its robust construction ensures long-lasting service. Whether you're maintaining batteries for a boat, RV, or other vehicle, this charger provides reliable, efficient, and safe charging performance to keep you ready for every adventure.

Features:

• Selectable charge profiles for lead-acid, AGM, and lithium batteries

• Automatic battery state of charge checking with intelligent algorithm

• Activation mode with voltage pulse to wake sleeping lithium batteries

• Manual activation mode for user control

• Designed for year-round use with plug-in convenience

• Over-voltage, over-current, short circuit, reverse polarity, and over-temperature protection

• Compact and durable IP68 rated enclosure for demanding environments

• Low input current with standard AC 110-120V power supply

• Maximum output voltage tailored for different battery types

• Lightweight design at approximately 9.5 lbs for easy installation
