ProMariner ProIsoCharge180 Battery Isolator for 12V Systems with 180 Amp Output

ProIsoCharge Series

Model ProIsoCharge180 12
Part No. 23122
System Volts DC 12
Max DC Amps 180 Amp
Alternator Input1
Battery Outputs 2
Size 6.15"(l) x 5.875"(w) x 3.125"(h)
Weight3 lbs

Significantly Smarter...
ProIsoCharge delivers digitally controlled alternator output distribution while protecting the health of engine start batteries. An industry changing design that provides intelligent and zero voltage loss isolation, charging of up to 3 other battery banks off a single alternator (model specific). For dual engine applications, ProIsoCharge offers an exclusive 2 alternator input model with up to 4 battery banks. Smart enough to provide priority charging to a battery bank that's under load by taking fully charged batteries off line. The all-in-one design eliminates the need for multiple voltage sensitive relays to charge multiple battery banks simultaneously, saving space, installation time and cost. Ensuring fully charged batteries and faster charge times, ProIsocharge eliminates the typical alternator voltage loss of 0.6VDC that's commonly associated with traditional diode based isolators. Installed with the ProNauticP Series, a boat owner can enjoy the full benefit of shore power and on the water charging. Designed to provide more time on the water enjoying what you like most... boating.

Intelligent Alternator Power Distribution System

ProMar Digital Performance Zero Volt Loss Isolation and Charging
All digital design delivers active battery status and automatic engine battery healthpriority while digitally distributing the full output of your engine's alternators.

Intelligent Isolation and Charging Software Control
ProIsoCharge's intelligent software control provides priority charging to a battery bank thatis under load (i.e house bank or power inverter bank) by taking fully charged batteries off lineand priority charging discharged battery banks, while insuring the health of the engine batteries.

Real Time LED Status Indicators
Highly visible LEDs to indicate alternator power is present and battery bank charging status.Fault LEDs include: high and low alternator output, over-voltage protection and high voltageconditions that may be present on any one of the battery banks connected (that are alsoconnected to other charging sources gen set combi etc).

Ignition Controlled
Distributed On Demand battery bank management will only activatewith ignition power on.

Advance Regulator Ready
Advance regulator remote sense connection provided for precision alternatoralgorithm control for alternators equipped with an advanced regulator.

Easy Installation
Modular design for easy install. Includes all terminal stud insulator bootsand protective snap on safety cover.

Built-in Safety
Ignition protected and waterproof to IP66. FIVE YEAR

WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

The ProMariner ProIsoCharge180 Battery Isolator is a sophisticated digital power distribution system designed for marine and vehicle applications requiring reliable and efficient battery management. With a compact size of approximately 6.15 inches in length, 5.88 inches in width, and 3.13 inches in height, and weighing just 3 pounds, this unit offers easy installation and space-saving benefits. Its primary function is to electronically distribute alternator power while protecting engine start batteries, ensuring optimal performance and longevity of your battery banks.
The ProIsoCharge180 features digitally controlled alternator output distribution that intelligently manages multiple battery banks, up to four in dual engine setups, with a maximum DC current of 180 amps. The system provides zero voltage loss isolation, significantly reducing the voltage drop typically experienced with traditional diode-based isolators. This results in faster charging times and fully charged batteries, enhancing your system’s efficiency. The unit's advanced software dynamically prioritizes charging to batteries under load, such as house banks or inverter banks, while safeguarding engine start batteries from overcharging or depletion.
Operation is simplified with real-time LED indicators that display alternator power status, charging progress, and fault conditions such as over-voltage or high voltage scenarios. The system is ignition-controlled, activating only when the engine is running, and features an advance regulator remote sense connection for precise alternator control when used with compatible regulators. Its waterproof and ignition-protected design ensures durability in demanding marine environments, meeting IP66 standards. The all-in-one design eliminates the need for multiple relays, reducing installation complexity and costs, making it an excellent choice for boat owners and vehicle enthusiasts seeking reliable, intelligent battery management solutions. Compatible with shore power and onboard charging systems, the ProIsoCharge180 enhances your power system’s performance, allowing more time to enjoy your activities without battery concerns. For detailed installation instructions, consult the included manual available online.

Features:

• Model: ProIsoCharge180 12 with a maximum of 180 DC amps output

• Digital power distribution with zero voltage loss isolation

• Supports up to four battery banks, ideal for dual engine applications

• Intelligent software control prioritizes charging based on load and battery health

• Real-time LED indicators display system status and faults

• Ignition-controlled operation activates only when the engine is running

• Remote sense connection for precise alternator regulation

• Compact, waterproof, and ignition protected design (IP66)

• Includes all terminal insulators and safety covers for easy installation

• Built-in safety features protect against over-voltage and high voltage conditions
