SKU:67247
5A Non-Isolated Step-Down 24VDC-12VDC Converter
This high efficiency switch-mode step-down DC-DC converter converts an input voltage of 24 VDC nominal (range 20 VDC to 35 VDC) to a highly regulated output voltage of 12 VDC nominal (13.8 VDC) at 20 Amps. The SDC-23 DC-DC converter is non-isolated (no galvanic isolation between input and output) and meant for use in negative ground systems. Features include overvoltage/short-circuit protection, temperature compensated current limit, output-side overvoltage protection, input-side overvoltage/ transient protection and input-side reverse polarity protection. The SDC-23 DC-DC converter is designed for heavy duty applications.
Features:
Specifications:
Applications:
WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.
The Samlex America SDC-5 is a high-performance, 5-amp non-isolated step-down DC-DC converter designed to efficiently convert 24 VDC nominal input (range 20 VDC to 35 VDC) to a stable 12 VDC output at up to 20 amps. Its advanced switch-mode design ensures high efficiency and reliable operation across demanding environments. This compact and lightweight module can be mounted in various locations, making it suitable for a wide range of mobile and stationary power systems. The converter features comprehensive protection mechanisms including overvoltage, short-circuit, reverse polarity, and transient input protection, ensuring safety and longevity in heavy-duty applications. Its temperature-compensated current limiting circuit provides stable operation even under fluctuating conditions, making it ideal for use in earth-moving equipment, heavy trucks, buses, marine vehicles, CB radios, and lighting or sound systems operating at 12 volts.
Features:
