Scandvik Utility Light - Cool White, 10-30V DC, 10 Watt, Model 41590P

Utility Light - Cool White - 10-30V

This is a surface-mount, low-profile E-330 LED compact engine room light. The white plastic end cap features a notch on the wire side to allow side access for the connection wires. A low-profile fixture extends a mere 5/8" from the mounting surface.

Features:

• 12/24 Volt (10-30 VDC) - 10 Watt
• 33 x 0.5-watt 2835 LEDs
• Cool white (5700-6300K)
• Polycarbonate lens with plastic housing
• IP67
• Meets requirements and standards for SAE J1171 USCG, ABYC NMMA

Specifications:

• Lumens: 727
• Beam Angle: 120
• Surface Mount (wire can exit from the bottom or end of the fixture)

*The "P" within the part number indicates retail packaging

The Scandvik Utility Light Model 41590P is a compact, surface-mount LED fixture designed for versatile use in engine rooms, boats, and other marine applications. It features a low-profile design that extends only about 5/8 inch from the mounting surface, making it an ideal choice where space is limited. The durable polycarbonate lens and plastic housing provide excellent protection against water and environmental elements, meeting IP67 standards for water and dust resistance. This fixture utilizes 33 high-efficiency 2835 LEDs producing a bright cool white light with a color temperature between 5700K and 6300K, delivering a total lumen output of 727 lumens with a wide 120-degree beam angle for broad illumination coverage. Designed for 12 and 24-volt systems, it operates efficiently within a 10-30V DC range, consuming only 10 watts of power while providing reliable, maintenance-free lighting in demanding environments. The fixture's wire connection features a notch on the plastic end cap, allowing side access for easy wiring from either the bottom or end of the fixture, simplifying installation. Certified to meet standards set by SAE J1171, USCG, ABYC, and NMMA, this LED utility light combines robust construction with high performance, ensuring long-lasting service and safety in marine or industrial settings. Whether used for task lighting, engine compartments, or exterior applications, the Scandvik Utility Light offers a compact, efficient, and durable lighting solution that enhances safety and visibility in challenging environments.

Features:

• Voltage Range: 12/24 Volt (10-30 VDC) for versatile application

• Power Consumption: 10 Watt for efficient operation

• LED Configuration: 33 x 0.5-watt 2835 LEDs for bright illumination

• Color Temperature: Cool white (5700-6300K) for clear visibility

• Lens Material: Polycarbonate for impact resistance and durability

• Housing Material: Plastic, lightweight yet sturdy

• Water Resistance: IP67 rated for protection against dust and water ingress

• Standards Compliance: Meets SAE J1171, USCG, ABYC, NMMA requirements

• Beam Angle: 120 degrees for wide illumination coverage

• Mounting: Surface mount with wire exit options from bottom or end for flexible installation
