Shakespeare 5241-R VHF Marine Antenna - Compact 3 Foot Heavy-Duty End-Fed Antenna for Boats

Shakespeare Style 5241-R VHF Marine
36 LENGTH 3dB
LOW PROFILE END-FED 1/2-WAVE WITH HEAVY-DUTY WHIP

The perfect choice for bass boats, center console fishing boats, or any vessel where compact size is most important. Comes with a heavy-duty stainless steel whip for extra stability at high speeds. Chrome plated brass canister minimizes de-tuning.

• Sealed, tin-plated copper wire coil

• Requires mount with center hole for passage of the supplied 15' RG-58 cable.

• PL-259 connector included

• Stainless steel whip (36)

• Suggested mount: Shakespeare Styles 4187, 4188-S, or 4190 Ratchet Mounts

• Shakespeare Limited Warranty: 2 years

Technical Specifications:

Frequency:	VHF Marine Band
Bandwidth:	7 MHz
SWR:	1.5:1 at 156.8 MHz
Radiation pattern:	Omni-directional
Gain:	3 dB
Max Input (Watts):	50 watts
DC Ground:	YES
Height (feet):	3
Polarization:	Vertical

The Shakespeare 5241-R VHF Marine Antenna is designed for optimal performance on bass boats, center console fishing vessels, and other compact watercraft where space is limited. With a length of approximately 3 feet, this low-profile end-fed half-wave antenna provides a reliable 3 dB gain and a bandwidth of 7 MHz, ensuring clear communication across the VHF Marine Band. Its omni-directional radiation pattern allows for consistent signal transmission and reception regardless of vessel orientation, making it a dependable choice for marine communication needs. The antenna's stainless steel whip enhances durability and stability at high speeds, while the chrome-plated brass canister minimizes de-tuning caused by environmental factors. This antenna is equipped with a sealed, tin-plated copper wire coil and includes a PL-259 connector for easy installation. The mounting requires a center hole to pass the supplied 15-foot RG-58 cable, compatible with Shakespeare styles 4187, 4188-S, or 4190 ratchet mounts.

Constructed to withstand harsh marine conditions, the Shakespeare 5241-R features a DC ground for optimal performance and safety. It handles up to 50 watts of input power, making it suitable for most marine VHF radios. The antenna's height of approximately 3 feet allows for effective signal propagation without excessive protrusion from the vessel, maintaining a low profile for streamlined operation. Backed by a two-year limited warranty, this antenna ensures long-term durability and reliable communication when navigating busy waterways or open seas. Whether you need a replacement or an upgrade, the Shakespeare 5241-R offers a blend of performance, durability, and ease of installation, making it a top choice for serious boaters and anglers alike.

Features:

• Length: Approximately 3 feet for compact installation on various vessels

• Gain: 3 dB for enhanced signal strength

• Bandwidth: 7 MHz to cover VHF Marine Band frequencies

• SWR: 1.5:1 at 156.8 MHz for efficient transmission

• Radiation Pattern: Omni-directional for consistent coverage

• Max Input Power: 50 watts suitable for most marine radios

• Heavy-duty stainless steel whip for stability at high speeds

• Chrome-plated brass canister minimizes de-tuning

• Includes PL-259 connector for easy setup

• Requires a center-hole mount with compatible Shakespeare ratchet mounts

• Sealed, tin-plated copper wire coil for durability

• DC Ground: Yes for safety and performance

• Warranty: 2 years from Shakespeare for peace of mind
