Simrad NAC-D Autopilot Computer

Comprehensive Overview of Simrad NAC-D Autopilot Computer

Simrad NAC-D Autopilot Computer

Model: 000-15621-001

• SeaStar Solutions(R), Volvo(R), Yanmar(R) and Yamaha(R) approved control system interface
• Control via APTM 44, AP 48 or easily integrate with your Simrad(R) multifunction display
• No need for an additional hydraulic pump, rudder sensor, or dockside calibration
• SteadySteerTM feature included
• Steer to a waypoint, heading or set turn pattern, such as a U turn, Spiral turn and many more - the NACTM -D can even initiate a zigzag turn
• CAN-bus data connectivity - connection to Optimus(R) steering systems via the CAN-bus data network
• Full system integration with Simrad(R) navigation systems via NSSTM and NSOTM multifunction display ranges

NACTM -D is a steer-by-wire autopilot solution for Electronic Vessel Control Systems (steering systems with a digital interface).

With NAC -D, boaters with SeaStar(R) Optimus(R), Yanmar(R) VC10/JC10, Volvo(R) IPS/EVC or Yamaha(R) helm master/single engine control systems can benefit from all the full features and performance of Simrad(R) autopilots.

Requires only the connection of two Micro-C connectors - there is no requirement for an additional hydraulic pump, rudder sensor installation or dockside rudder calibration. This saves boaters' time and money.

Featuring Continuum(R) steering and support for the new SteadySteerTM, the NAC -D allows automatic switching between two speed profiles delivering optimal steering performance at both low and high speeds.

Choose the controller to suit your preference from dedicated controllers like the APTM 44 or AP 48, or simply integrate with your Simrad(R) multifunction display.

Simrad(R) autopilot systems incorporate state-of-the-art electronics and represent over 70 years of experience and development. Simrad(R) autopilots can reduce your workload and fatigue and improve your situational awareness and safety, helping you arrive fresher at your destination.

Specifications

Compass sensor supportNMEA 2000

Drive output
EVC

Engine Drive systems integration
Volvo EVC, Yamaha, Yanmar, Optimus

Manouevres / Turn Patterns
C-turn, U-turn, Zigzag turn, Square turn, S-turn, Depth counter tracking (DCT)

Connectivity

NMEA 2000
2 x NME2000 Micro-C port, 2 LEN

Electrical

Power Consumption, max.
40mA

Power Consumption, typical
40mA

Supply Voltage
9-16V via CAN

Environment

Operating Temperature Range
0C to +55C (+32F to +131F)

Storage Temperature Range
-30C to +70C (-22F to +131F)

Waterproof rating
IP44

Compass Safe Distance - Metric, imperial
0,5m (19,7)

Physical

Dimensions (W x H x D)
86

Advanced Technology Driving Simrad NAC-D Performance

The Simrad NAC-D autopilot computer is engineered with cutting-edge technology designed to enhance vessel navigation. It seamlessly integrates with existing marine systems to provide precise steering control. This autopilot computer boasts reliable algorithms that adapt dynamically to varying sea conditions, ensuring smooth course adjustments. Its compatibility with GPS and radar input allows for accurate route tracking and collision avoidance. Operators benefit from reduced fatigue and improved safety, making the Simrad NAC-D an essential tool for professional and leisure sailors alike.

Robust Design for Harsh Marine Environments

Durability is a hallmark of the Simrad NAC-D autopilot computer, built to withstand demanding marine conditions. The unit features waterproof and corrosion-resistant components, crucial for long-term reliability on the water. Its compact design saves valuable dashboard space without compromising functionality. Installation is straightforward, and the system is designed for minimal maintenance. This autopilot computer excels in performance even during rough seas, offering dependable operation and resilience that boat owners can trust.

User-Friendly Interface and Integration

The Simrad NAC-D features an intuitive user interface that simplifies autopilot operations. With easy-to-navigate controls, users can quickly set waypoints and adjust steering modes according to their preferences. The system integrates smoothly with Simrad’s multifunction displays, allowing centralized command of navigation data. Real-time feedback and customization options enhance user control over vessel handling. This accessibility makes the Simrad NAC-D ideal for both experienced mariners and beginners seeking reliable autopilot assistance.
