Sitex SAS-900 Class A AIS

Sitex SAS-900 Class A AIS

Model: SAS-900

• Internationally certifed SOLAS, MED, FCC, Inland Waterway, Industry Canada


• IPx6 & IPx7 water and weather proof


• Inter-operable with all other bridge system


• High performance detailed Electronic Charts - C-Map


• Multi-lingual, intuitive user interface


• MOB & SART alert and tracking


• Integrated WiFi


• NMEA0183 & 2000

SAS-900 is the world’s most sophisticated and robust SOLAS and Inland-Waterway certified AIS Class A Transceiver.

Fourth generation AIS technology delivers unmatched real world AIS receive, transmit and message processing performance and reliability. Quality engineered and manufactured without compromise, with features such as IPx7 weather proofing and integrated shock & vibration protection for continuous long term operation in even the harshest commercial or military environment.

A large integrated high definition color screen maximizes the benefit of the SAS-900’s powerful Electronic Chart display engine with full detailed chart AIS overlay, and multiple target management functionality, including innovative MOB features and many more.

Specifications

Dimensions
152mm x 165mm x 111mm

Weight
1.5kg

Electrical

Power supply
12 to 24VDC

Power consumption
< 12W

Connectors

VHF antenna connector
SO-239 / UHF

GNSS antenna connector
TNC

Power
Two pin connector (cable provided)

Serial interfaces and alarm relay
18 pin connector (cable provided)

Serial inputs
14 pin connector (cable provided)

NMEA2000®
NMEA 2000 Micro connector

Data Interfaces

NMEA0183 (IEC61162-2) bi-directional ports
3

NMEA0183 (IEC61162-1) sensor inputs
3

DGPS correction data input (ITUR M.823-2)
1

Alarm relay output
1

NMEA2000
1

WiFi
802.11 b/g/n

Pilot port
1 (optional)

VHF Transceiver

Transmitter
1

Receiver
3

Frequency
156.025MHZ to 162.025MHz

Output power
1W or 12.5W (automatic)

Channel bandwidth
25kHz

Channel step
25kHz

Modulation modes
GMSK-TDMA

Bit rate
9600bits/sec

Receiver sensitivity
-107dBm @ 20% PER

GNSS Receiver and Antenna

Channels
72

GNSS systems
Support parallel dual mode operation from GPS and GLONASS

IEC61108-1 Complian
Compliant

GNSS antenna
Supplied

What's in the Box:

• SAS900


• Mounting bracket


• GOS Antenna with cable


• 18 way data cable


• 14 way data cable


• Power cable


• Mounting hardware


• Documentation
