SKU:88485
Blue Smart IP22 12VDC 20A 1 Bank 120V Charger - Dry Mount
The Blue Smart IP22 Charger is the professional battery charger with built-in bluetooth. The Blue Smart IP22 Charger can be used on devices in your workshop and on motor vehicles, such as (classic) cars; motorbikes; boats and camper-vans.
Bluetooth Smart
The Blue Smart IP22 Charger is the wireless solution to monitor voltage and current, to change settings and to update the charger when new features become available.
High efficiency
With up to 94% efficiency, these chargers generate up to four times less heat when compared to the industry standard. And once the battery is fully charged, power consumption reduces to 0,5 Watt, some five to ten times better than the industry standard.
Adaptive 6-stage charge algorithm: test - bulk absorption - recondition float storage
The Blue Smart Charger features a microprocessor-controlled adaptive battery management. The adaptive feature will automatically optimize the charging process relative to the way the battery is being used.
Storage Mode: less maintenance and aging when the battery is not in use
The storage mode kicks in whenever the battery has not been subjected to discharge during 24 hours. In the storage mode float voltage is reduced to 2,2V/cell (13,2V for a 12V battery) to minimize gassing and corrosion of the positive plates. Once a week the voltage is raised back to the absorption level to equalize the battery. This feature prevents stratification of the electrolyte and sulfation, a major cause of early battery failure.
Also charges Li-ion batteries
Li-ion batteries are charged with a simple bulk absorption float algorithm.
Fully discharged battery recovery function
Will initiate charging even if the battery has been discharged to zero volts. Will reconnect to a fully discharged Li-ion battery with internal disconnect function.
NIGHT and LOW setting
When in NIGHT or LOW mode, the output current is reduced to max. 50% of the nominal output and the charger will be totally noiseless. The NIGHT mode automatically ends after 8 hours. The LOW mode can be ended manually.
Protected against overheating
Output current will reduce as the temperature increases up to 50C, but the Blue Smart Charger will not fail.
Eleven LEDs for status indication
Charge algorithm: TEST / BULK / ABSORPTION / RECONDITION / FLOAT / STORAGE / READY. MODE button to set: NORMAL (14,4V) / HIGH (14,7V) / RECONDITION / LI-ION.
Please contact your dealer for any returns, repairs or support issues related to this product.The Victron Blue Smart IP22 Charger is a versatile and professional-grade battery charger designed for use in workshops, on vehicles, and marine applications. Featuring built-in Bluetooth connectivity, this charger allows remote monitoring of voltage and current, adjustment of settings, and firmware updates via a compatible app, providing convenience and control at your fingertips. Its compatibility extends to various battery types, including lead-acid and lithium-ion, making it suitable for cars, motorbikes, boats, and camper-vans, ensuring reliable power management across multiple use cases.
Built with high efficiency in mind, the Blue Smart IP22 achieves up to 94% efficiency, generating less heat compared to standard chargers. This results in better performance and longer device lifespan. Once the battery reaches full charge, power consumption drops to just 0.5 watts, which is significantly lower than industry standards. The charger uses an adaptive 6-stage charge algorithm that includes testing, bulk, absorption, reconditioning, float, and storage modes. This microprocessor-controlled process optimizes charging based on the battery's current condition, promoting battery health and longevity.
The storage mode feature minimizes maintenance and aging when the battery is not in use for an extended period. When the battery remains discharged for over 24 hours, the charger reduces float voltage to prevent gassing and corrosion, with weekly equalization to prevent electrolyte stratification and sulfation. The charger also supports charging of lithium-ion batteries using a simplified bulk, absorption, and float process. Additionally, it can recover fully discharged batteries, including those down to zero volts, and reconnects to internally disconnected Li-ion batteries.
With operational modes such as NIGHT and LOW, the charger can reduce output current to a maximum of 50%, making it silent and ideal for overnight or low-noise environments. The NIGHT mode automatically ends after 8 hours, while LOW mode can be manually terminated. The device features over-temperature protection, reducing output current if ambient temperatures exceed 122°F, ensuring safety without failure. Eleven LEDs provide clear status indicators for each stage of the charging process, including test, bulk, absorption, reconditioning, float, storage, and ready. Mode settings include NORMAL, HIGH, RECONDITION, and LI-ION, offering flexible operation tailored to your needs.
Designed for durability and reliability, the Victron Blue Smart IP22 Charger is an excellent choice for maintaining optimal battery performance in a variety of applications. Its compact design allows for easy installation with dry mounting options, making it suitable for both stationary and mobile setups. For detailed instructions and support, refer to the official owner's manual available online.
