Victron Energy BMV-712 Black Smart Battery Monitor with Bluetooth and IoT Connectivity

BMV-712 Black Smart Battery Monitor

With Bluetooth built-in, the BMV Smart is ready for the Internet of Things (IoT) era. With Bluetooth being implemented in most other Victron Energy products, wireless communication between products will simplify system installation and enhance performance.

Features:

• Battery voltage, current, power, ampere-hours consumed and state of charge
• Remaining time at the current rate of discharge
• Programmable visual and audible alarm
• Programmable relay, to turn off non critical loads or to run a generator when needed
• 500 Amp quick connect shunt and connection kit
• Shunt selection capability up to 10.000 Amps
• VE.Direct communication port
• Stores a wide range of historical events, which can be used to evaluate usage patterns and battery health
• Wide input voltage range: 6,5 70V
• High current measurement resolution: 10 mA (0,01A)
• Additional input to measure voltage (of a second battery), temperature or midpoint voltage, and corresponding alarm and relay settings

VictronConnect

VictronConnect lets you get live status information and configure any Victron products which either have Bluetooth built-in, or are connected to a VE.Direct Bluetooth Smart Dongle.

Warranty Info

WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

The Victron Energy BMV-712 Black Smart Battery Monitor offers advanced monitoring capabilities for your battery system, designed to provide real-time data and enhance overall performance. Featuring built-in Bluetooth, this device seamlessly integrates with your existing Victron products, simplifying system installation and enabling wireless communication across your setup. With comprehensive metrics such as voltage, current, power, ampere-hours consumed, and state of charge, users can easily track battery health and usage patterns through compatible apps. The monitor also displays the estimated remaining time at the current discharge rate, empowering users to make informed decisions about power management.
The BMV-712 includes a programmable visual and audible alarm system to alert you of critical conditions, along with a relay that can be configured to turn off non-critical loads or activate a generator when necessary. The device connects via a 500 Amp quick connect shunt, with the capacity to measure up to 10,000 Amps, ensuring accurate current measurement for larger systems. Additionally, the VE.Direct communication port allows for wired data transfer, while the device’s ability to store historical event data helps in evaluating battery performance and predicting maintenance needs.
Designed to operate across a wide input voltage range from 6.5V to 70V, the BMV-712 provides high-resolution current measurements at 10 mA (0.01A), ensuring precise monitoring even in demanding applications. An extra input allows for additional measurements such as voltage of a secondary battery, temperature, or midpoint voltage, with configurable alarms and relays for comprehensive system management. Compatible with the VictronConnect app, the monitor enables live status updates and configuration adjustments via Bluetooth, streamlining setup and ongoing maintenance.
For detailed installation instructions, refer to the official owner’s manual available online. Please note that this product may contain chemicals known to the State of California to cause cancer and reproductive harm, as detailed on the P65Warnings website. For support, repairs, or returns, contact your authorized dealer to ensure proper service and assistance.

Features:

• Battery voltage, current, power, ampere-hours consumed, and state of charge measurement

• Estimated remaining time at current discharge rate

• Programmable visual and audible alarms

• Configurable relay for load management or generator control

• 500 Amp quick connect shunt with capacity up to 10,000 Amps

• VE.Direct communication port for wired data transfer

• Stores historical event data for system analysis

• Wide input voltage range from 6.5V to 70V

• High-resolution current measurement at 10 mA (0.01A)

• Additional input for secondary battery voltage, temperature, or midpoint voltage with alarm and relay settings

• Bluetooth connectivity with VictronConnect app for real-time monitoring and configuration
